Lightware RAP-B511-EU-K User Manual

Room automation panel
Table of Contents

Advertisement

Quick Links

User's Manual
RAP-B511-EU -K, -W, -S
RAP-B511-UK -K, -W, -S
RAP-B511-US -K, -W, -S
Room Automation Panel

Advertisement

Table of Contents
loading

Summary of Contents for Lightware RAP-B511-EU-K

  • Page 1 User’s Manual RAP-B511-EU -K, -W, -S RAP-B511-UK -K, -W, -S RAP-B511-US -K, -W, -S Room Automation Panel...
  • Page 2     RAP-B511 series – User's Manual Important Safety Instructions Waste Electrical & Electronic Equipment Common Safety Symbols WEEE Class II apparatus construction. This marking shown on the product or its literature, The equipment should be operated only from the power source indicates that it should not be disposed with other indicated on the product Symbol...
  • Page 3 The following symbols and markings are used in the document: All presented functions refer to the indicated products. The descriptions Lightware Visual Engineering supports green technologies and have been made during testing these functions in accordance with the Eco-friend mentality. Thus, this document is made for digital usage...
  • Page 4: Table Of Contents

    2.1.6. Mounting RAP-B511-US into the Outlet Box ........12 4.5.4. Infra Interface .................. 24 6.2.7. View Serial Number ................. 41 2.2. Powering Options ...............13 5. SOFTWARE CONTROL - LIGHTWARE DEVICE CONTROLLER ..25 6.2.8. Compile Time ................... 41 2.3. Connecting Steps................13 5.1. Install and Upgrade ..............25 6.2.9. View Installed Board ............... 41 3.
  • Page 5     RAP-B511 series – User's Manual 7. LW3 PROGRAMMERS’ REFERENCE ..........44 7.7. Button Group Configuration .............53 7.14. Sending Message via the Communication Ports ......60 7.7.1. Set the Buttons into Groups ............53 7.14.1. Sending Message via TCP Port ............ 60 7.1. Overview ..................44 7.7.2. Query the Group Members ..............
  • Page 6: Introduction

    RAP-B511-UK-S brushed steel cabling flexible and can supply PoE when an AC adapter is plugged in. RAP-B511-US-K black Thank you for choosing Lightware’s RAP-B511 series device. In the first Model Denomination RAP-B511-US-W white Double US wall box chapter we would like to introduce the device highlighting the most important...
  • Page 7: Features Of The Device

    Infrared (IR) is a wireless technology used for device communication over short ranges. Third party control systems may send IR control commands to endpoints turning them on and off or switching their inputs. The Lightware Device Controller (LDC) application keeps receiving upgrades adding new Conditions Actions features and tools.
  • Page 8     1. Introduction RAP-B511 series – User's Manual Meeting Room Application Example Conference Room Application Example CATx RS-232 HDMI Analog audio CATx Reset RS232 HDMI AUDIO AUDIO Analog audio Relay GPIO GPIO TPS+P TPS+P TPS+P TPS+P TPS+P TPS+P Hunga Made...
  • Page 9: Installation

    Outlet Box, 2-Gang, Depth: 2-3/4”) INFO: The outlet box is not supplied in the mounting kit. Please contact sales@lightware.com for the availability. 2.1.2. Label and Cap Fixation The caps of the buttons are supplied separately with the product in a plastic bag. Select the desired label and insert it as shown in attached figure: Step 1.
  • Page 10: Mounting Rap-B511-Eu Into The Outlet Box

        2. Installation RAP-B511 series – User's Manual 2.1.4. Mounting RAP-B511-EU into the Outlet Box Step 3. Insert the Button panel into the Outlet box and position it to get the holes aligned. Step 1. Pull apart the Front plate from the Button panel by your hand (no special tool needed). t l e t b o x t t o...
  • Page 11: Mounting Rap-B511-Uk Into The Outlet Box

        2. Installation RAP-B511 series – User's Manual 2.1.5. Mounting RAP-B511-UK into the Outlet Box Step 3. Insert the RAP-B511-UK into the Outlet box and position it to get the holes aligned. Step 1. Pull apart the Front plate from the RAP-B511-UK by your hand (no special tool needed). t l e t P - B b o x...
  • Page 12: Mounting Rap-B511-Us Into The Outlet Box

        2. Installation RAP-B511 series – User's Manual 2.1.6. Mounting RAP-B511-US into the Outlet Box Step 3. Insert the RAP-B511-US into the Outlet box and position it to get the holes aligned. Step 1. Pull apart the Front plate from the RAP-B511-US by your hand (no special tool needed). t l e t P - B b o x...
  • Page 13: Powering Options

    2.3. Connecting Steps RAP-B511 series automation panel is compatible with IEEE 802.3af standard - Power over Ethernet (PoE) - Projector Lightware device Relay box and one Ethernet port can receive, and the other one can send power over the Ethernet line.
  • Page 14: Product Overview

    / low bright / high bright / slow blink / sine pulse. Blinking of the button and rotary LEDs three times means, that the front panel functionality is locked. Unlocking is possible with Software Control - Lightware Device Controller or via LW3 protocol commands (for more details see LW3 Programmers’...
  • Page 15: Hidden Functions

        3. Product Overview RAP-B511 series – User's Manual 3.1.1. Hidden Functions Restore Factory Default Settings Step 1. Keep the 2nd button pressed for 10 seconds; after 5 seconds front After removing the front plate (no special tool needed, just pull apart panel LEDs start to blink but keep the button pressed;...
  • Page 16: Electrical Connections

    Wiring of LAN Cables Pin nr. Signal Input Output Max. output Lightware recommends the termination of LAN cables on the basis of voltage [V] voltage [V] current [mA] TIA/EIA T 568 A or TIA/EIA T 568 B standards. Logical low level 0 - 0.8...
  • Page 17: Device Concept

    4.1. General Concept Room automation panel is designed for advanced control functions. Industrial standard communication interfaces (RS-232, Ethernet, GPIO, IR) ensure the compatibility with third-party units or Lightware products. They make possible to automate the whole AV system in a huddle room.
  • Page 18: Inputs 1. - User Interactions

    / false Not extecuted Button release Radio Group INFO: All settings of the button functions are available in the Lightware Device Contoller software (see the details in Buttons section) or via LW3 protocol commands (for more details see Button Configuration...
  • Page 19: Rotary

    Configurations of the Rotary section) or with LW3 protocol commands (for more details INFO: All settings of the Real-time clock is possible using the Lightware Device Contoller software (see Volume Control Configuration section). the details in...
  • Page 20: Recognizer

    AUTO (e.g. 'the lamp is turned off'). Click Ok to save. The RS-232 recognizer settings has to be done with Lightware Device Controller Software (see RAP-B511 Relay box...
  • Page 21: Ir Recognizer

    LED lights) or a control signal to the other device. Outputs can be set in the UI Config Menu (and in the Event Manager) in theSoftware Control - Lightware Device Controller (LDC) software. INFO: All settings are available in the LDC software, more details can be found in the Infra section.
  • Page 22: Rotary Leds

    The RS-232 port settings (baud rate, data bits, parity, stop bits) of the connected serial devices must be the same. Projection ▪ The RS-232 port of the RAP-B511 must be in Disconnect mode. (If the target device is also Lightware screen unit, take care of the its operation mode, too) AUTO Pay attention to the correct serial cabling (connector pinout).
  • Page 23: Settings For Other Interfaces

    Disconnect Mode establish a connection to Lightware Device Controller. For more information about the LDC, see Software This mode is for sending control commands to a third-party (or a Lightware) device from the RAP-B511. Control - Lightware Device Controller section.
  • Page 24: Infra Interface

        4. Device Concept RAP-B511 series – User's Manual 4.5.4. Infra Interface Technical background RAP-B511 contains dedicated IR in connection and is able to receive IR signal via the built-in IR detector units. The signal is stored in hash (fingerprint)format. With the help of the device's IR recognizer functionality you can assign actions in Event manager (for more details, see IR Recognizer...
  • Page 25: Software Control - Lightware Device Controller

    The device can be controlled by a computer through the Ethernet and RS-232 traverse the update process, set the proper values then click Normal install Snapshot install port using Lightware Device Controller (LDC). The software can be installed the OK button. Available for Windows and macOS Available for Windows on a Windows PC or macOS.
  • Page 26: Establishing The Connection

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual Connecting to a Device via a Serial Port Step 3. Select the unit from the discovered Ethernet devices or under Serial devices; when the device is connected through RS-232 click on the Query button next to the desired serial port to display the Format: LightwareDeviceController -c <COM_port>:<Baud>...
  • Page 27: Ui Config Menu

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.4. UI Config Menu Information ribbon The label shows the device label which can be edited in the Settings menu Status tab. Device discovery window can be displayed by clicking on this ribbon.
  • Page 28: Button Properties

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.4.1. Button Properties The tab denomination depends on the button operation mode. A short description gives a hint to choose the proper condition or action for the selected button.
  • Page 29: Button Interactions

    Clear All button is for deleting all events of the selected button. ▪ Lightware device, see the table on the next page). The mute and level entry fields are inactive, because after giving the audio port number (e.g. I2 or O8), the command schema loaded automatically.
  • Page 30: Control Menu

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.5. Control Menu Step 3. Save the Schema by clicking Save Configuration to Device button. The configuration is saved to Events in the Event Manager (one event for one level settings).
  • Page 31: Gpio

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.5.2. GPIO Message recognizer RAP-B511 series button panel is able to analyze and store the received serial data. For more information see RS-232 Recognizer section.
  • Page 32: Ethernet

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.5.3. Ethernet 5.5.4. Infra Infra-Red (IR) receiver options can be found on this tab. There are three submenus are available under it: IR codes, Ports, and Clear all IR codes.
  • Page 33     5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual Ports Tab Description Function User can set the name and command injection port to each sources and destinations. For more details Code number. about IR interface see the Infra Interface section.
  • Page 34: Event Manager

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.6. Event Manager 5.6.1. Event Manager in the RAP-B511 The functionality of the Room Automation Panel based on the Event Manager. UI config page provides an The feature means that the device can sense changes on its ports and able to react interface where the events can be set easily and they are saved in the Event Manager.
  • Page 35: The Event Editor

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.6.2. The Event Editor 5.6.3. Create or Modify an Event Press the Edit button in the desired Event line to open the Event editor window. Wizard Mode...
  • Page 36: Special Tools And Accessories

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual Step 3. All the saved Events are analyzed and the conditions are listed (it takes some seconds to finish). no delay Condition = true...
  • Page 37: Settings Menu

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.7. Settings Menu Built-in Miniweb The built-in website makes possible to connect to the device, and query status information with a web browser. 5.7.1. Status System requirements for operating systems: Microsoft Windows XP, Windows Vista, Windows 7, Windows 10, macOS, Linux.
  • Page 38: System

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.7.3. System 5.8. Time Settings System tab in Settings menu Three functions are available under System tab: ▪ Download system log - saving the file of the device.
  • Page 39: Advanced View Window

        5. Software Control - Lightware Device Controller RAP-B511 series – User's Manual 5.9. Advanced View Window Set NTP (Network Time Protocol) settings ▪ Enable NTP makes possible to query time information from an NTP server. It means, that the RAP-B511 is permitted to get time information from an NTP server.
  • Page 40: Lw2 Programmer's Reference

    The device can be controlled through a reduced command set of LW2 protocol <loc> Location number in 1, 2 or 3 digit ASCII format commands to ensure the compatibility with other Lightware products. The supported LW2 commands are described in this chapter. <id>...
  • Page 41: Query Control Protocol

    Example Command {FC}  {fc} Explanation: The device reboots; no response is sent in this case. Response (CF●<DESC>)CrLf  (CF RAP-B511-EU-K v1.0.4b1) 6.2.11.  Query Health Status (CF END)CrLf  (SL END) Description: Internal voltages and measured temperature values are shown.
  • Page 42: Network Configuration

        6. LW2 Programmer's Reference RAP-B511 series – User's Manual 6.3. Network Configuration 6.3.4. Set the Gateway Address Description: Gateway address can be set as follows. 6.3.1. Query the Current IP Status Format Example Description: IP address settings can be queried as follows. Command {IP_GATEWAY=<gateway_addr>} ...
  • Page 43: Lw2 Commands - Quick Summary

        6. LW2 Programmer's Reference RAP-B511 series – User's Manual 6.5. LW2 Commands – Quick Summary General LW2 Commands See in Operation Command chapter View Product Type 6.2.1 View Device Label 6.2.2 {LABEL} Query Control Protocol 6.2.3 {P_?} View Firmware Version of the Package 6.2.4 View Firmware for All Controllers...
  • Page 44: Lw3 Programmers' Reference

    (Cr, ‘\r’) and line feed (Lf, ‘\n’) pair. It is organized as a tree structure that provides outstanding flexibility and user-friendly handling with ‘nodes’, ‘properties’ and ‘methods’. The Advanced View of the Lightware Device Controller software is the perfect tool for browsing and learning how the LW3 protocol can be used in practice.
  • Page 45: Command Types

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.2.3. Command Types 7.2.4. Prefix Summary DEFINITION: The prefix is a 2-character long code that describes the type of the response. GET command The following prefixes are defined in the LW3 protocol: The GET command can be used to get the child nodes, properties and methods of a specific node.
  • Page 46: Signature

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.2.7. Signature 7.2.9. Notifications about the Changes of the Properties DEFINITION: The signature is a four-digit-long hexadecimal value that can be optionally placed before When the value of a property is changed and the user is subscribed to the node, which the property belongs every command to keep a command and the corresponding responses together as a group.
  • Page 47: System Commands

    Ý GET /.ProductName The device can be restarted – the current connections (LAN, RS-232 Ý SET /SYS/MB/POE.PoeEnabled=true or USB) will be terminated. Ü pr /.ProductName=RAP-B511-EU-K Ü pw /SYS/MB/POE.PoeEnabled=true 7.3.2. Set the Device Label Command and Response INFO: The RAP-B511 sends PoE when the connected device is also ATTENTION! The device label can be changed to a custom text in Ý...
  • Page 48: Time Settings

    Disable getting NTP from DHCP server Ý SET /SYS/MB/TIMEZONE.Timezone=CET-1CEST,M3.5.0/2,M10.5.0/3 Example Ü pw /SYS/MB/TIMEZONE.Timezone=CET-1CEST,M3.5.0/2,M10.5.0/3 Ý SET /SYS/MB/NTP.NtpServerFromDhcp=true TIPS AND TRICKS: Timezone and daylight saving settings can be done easily and quickly with Lightware Ü pw /SYS/MB/NTP.NtpServerFromDhcp=true Device Controller software in Time Settings section.
  • Page 49: Synchronize With The Ntp Server

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.4.6. Synchronize with the NTP server 7.4.9. Query the Local Time (RTC) Command and Response Command and Response Ý GET·/SYS/MB/RTC.LocalTime Ý CALL·/SYS/MB/NTP:updateTime() pr·/SYS/MB/RTC.LocalTime=<localtime> Ü mO·/SYS/MB/NTP:updateTime Ü Parameters Example <localtime> Displays the date and the local time.
  • Page 50: Button Configuration

    When the button is released, the <btn_ID>.State does not change. ▪ Lightware Device Controller software or via protocol command. 2-6: Radio: It defines the assigned radio group of the button. One button can belong to one group at the same time.
  • Page 51: Set The Button Interaction State

    This property gives immediate feedback about the button status, which changes depending on the button Query the Latch mode. When the button function is configured with Lightware Device Controller Software, this parameter is Command and Response set as a Condition in the Event Manager.
  • Page 52: Button Led Configuration

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.6. Button LED Configuration Query the Clicked Status Command and Response General parameters Ý GET·/MANAGEMENT/UI/BUTTONS/<btn_ID>/BUTTON.Clicked Identifier Parameter description Parameter values pr·/MANAGEMENT/UI/BUTTONS/<btn_ID>/BUTTON.Clicked=<clicked_nr> <LED_ID> LED identifier (LED1 is behind the BUTTON1) LED1-11 Ü...
  • Page 53: Set The Background Light For A Period Of Time

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.7. Button Group Configuration Set the FalseFunction Here can define how the LEDs behave, when the button is pressed or released. This property takes into 7.7.1. Set the Buttons into Groups consideration the Set the Button Interaction State.
  • Page 54: Volume Control Configuration

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.8. Volume Control Configuration 7.8.3. Mute the Volume Clicking on the jog dial changes the mute state (and toggles on and off the mute LED). 7.8.1. Control Lock of the Jog Dial Command and Response This property can disable the control function of the jog dial without locking the buttons.
  • Page 55     7. LW3 Programmers’ Reference RAP-B511 series – User's Manual Query the Actual Status of the Rotary Command and Response Ý GET·/MANAGEMENT/UI/VOLUMECONTROL/ROTARY.ActualStatus pr·/MANAGEMENT/UI/VOLUMECONTROL/ROTARY.ActualStatus=<rotary_status> Ü Parameters Identifier Parameter description Parameter values <rotary_status> Shows if the rotary button is up: The rotary button is not pressed at the moment.
  • Page 56: Network Configuration

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.9. Network Configuration 7.9.4. Change the IP Address (Static) 7.9.8. Change the Gateway Address (Static) 7.9.1. Query the DHCP State Command and Response Command and Response SET·/MANAGEMENT/NETWORK.StaticIpAddress=<IP_address> SET·/MANAGEMENT/NETWORK.StaticGatewayAddress=<gw_add> Ý Ý Command and Response pw·/MANAGEMENT/NETWORK.StaticIpAddress=<IP_address>...
  • Page 57: Port Configuration

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.10. RS-232 Port Configuration 7.10.3. Databit Setting Ý SET /MEDIA/UART/P1.Parity=0 Ü pw /MEDIA/UART/P1.Parity=0 7.10.1. Protocol Setting Command and Response 7.10.6. RS-232 Operation Mode SET·/MEDIA/UART/P1.DataBits=<databit> Ý Command and Response Command and Response pw·/MEDIA/UART/P1.DataBits=<databit>...
  • Page 58: Recognizer

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.11. RS-232 Recognizer 7.11.3. Set the Timeout Parameters <recognized _hex> Recognized data in hex format. When the set time is elapsed after the last received message, the This tool is able to recognize the incoming RS-232 message. It stores device saves the data.
  • Page 59: Query The Last Recognized Serial Message

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.11.6. Query the Last Recognized Serial Message (ActiveRx, 7.11.7. Set the Active Timeout 7.13. GPIO Port Configuration ActiveRxHex, ActiveHash) This property is responsible for erasing the temporary storage 7.13.1. Set the Direction of a GPIO Pin (ActiveRx, ActiveRxHex, ActiveHash) after the elapsing time.
  • Page 60: Sending Message Via The Communication Ports

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.14. Sending Message via the Communication Ports 7.14.1.3. Sending a TCP Binary Message (HEX-format) The command is for sending a binary message in Hexadecimal format. This method does not allow escaping 7.14.1. Sending Message via TCP Port or inserting control characters.
  • Page 61: Message Sending Via Rs-232 Serial Port

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.14.2.2. Sending a UDP Text (ASCII-format) 7.14.3.2. Sending a Text (ASCII-format) via RS-232 The command is for sending a text message in ASCII-format via UDP-protocol. This method does not allow The command is for sending a command message in ASCII-format.
  • Page 62: Lw3 Quick Summary

        7. LW3 Programmers’ Reference RAP-B511 series – User's Manual 7.15. LW3 Quick Summary Query the Universal Time Coordinated Time (UTC) Ý GET·/SYS/MB/RTC.UtcTime System Commands Query the Local Time (RTC) Query the Product Name Ý GET·/SYS/MB/RTC.LocalTime Ý GET·/.ProductName Query the Local Time (RTC) Elements Set the Device Label GET·/SYS/MB/RTC.<RTC_element>...
  • Page 63     7. LW3 Programmers’ Reference RAP-B511 series – User's Manual Button Group Configuration Ý GET·/MANAGEMENT/NETWORK.NetworkMask Change the Subnet Mask (Static) Set the Buttons into Groups SET·/MANAGEMENT/NETWORK.StaticNetworkMask=<netmask> Ý Query the Group Members Query the Gateway Address Ý GET·/MANAGEMENT/UI/GROUP/<group_ID>.GroupMembers Ý...
  • Page 64     7. LW3 Programmers’ Reference RAP-B511 series – User's Manual Query the Last Recognized Serial Message (Rx, RxHex, Hash) Sending a UDP Binary Message (HEX-format) Ý GET·/MEDIA/UART/RECOGNIZER.Rx Ý CALL·/MEDIA/ETHERNET:udpBinary(<IP_address>:<port_no>=<HEX_message>) Ý GET·/MEDIA/UART/RECOGNIZER.RxHex Sending a Message (ASCII-format) via RS-232 Ý...
  • Page 65: Firmware Upgrade

    Installation modes the Lightware Device Updater v2 (LDU2) software. To get the latest software LDU2 has two installation modes: Normal and Snapshot. and firmware pack can be downloaded from www.lightware.com.
  • Page 66: Firmware Upgrading Steps

        8. Firmware Upgrade RAP-B511 series – User's Manual 8.3. Firmware Upgrading Steps Step 3. Press the Open button. The listed devices – which are compatible with the firmware pack – are filtered automatically in the main screen. Parameters button opens a window, where factory default ATTENTION! While the firmware is being upgraded, the normal operation mode is suspended as the restore can be chosen after the firmware upgrade.
  • Page 67: Troubleshooting

        9. Troubleshooting RAP-B511 series – User's Manual At first, check front panel LEDs and take the necessary steps according to their states. For more information about status, LEDs refer to Front View Rear View sections. Symptom Root cause Action RS-232 signal...
  • Page 68: How To Speed Up The Troubleshooting Process

    In the case of Event Manager issue the event file and/or backup file from the Device Controller ▪ software. The more of the above information you can give us the better. Please send these information to the Lightware Support Team (support@lightware.com) to speed up the troubleshooting process.
  • Page 69: Appendix

        10. Appendix RAP-B511 series – User's Manual 10.1. Specification Control Ethernet Connector type..............Locking RJ45 General Ethernet data rate....10/100Base-T, full duplex with autodetect Compliance ..................CE Power over Ethernet (PoE) ......PoE in (1x), PoE out (1x) Safety ..............IEC/EN 62368-1:2014 EMI/EMC ......
  • Page 70: Wiring Guide For Rs-232 Data Transmission

    IR port settings Equipment) or a DTE (Data Terminal Equipment) type device: Button enabled true Command injection status Enabled Lightware device and a DCE Lightware device and a DTE Operation mode Command injection input port nr. 9001 D-SUB 9 - Phoenix...
  • Page 71: Mechanical Drawings

        10. Appendix RAP-B511 series – User's Manual 10.4. Mechanical Drawings Dimensions are in mm. RAP-B511-UK -K, -W, -S RAP-B511-EU -K, -W, -S INFO: All the RAP-B511-UK models have the same size. INFO: All the RAP-B511-EU models have the same size. 2 gang EU Carlon 2 gang...
  • Page 72: Button Numbering

        10. Appendix RAP-B511 series – User's Manual 10.5. Button Numbering RAP-B511-US -K, -W, -S INFO: All the RAP-B511-US models have the same size. 115.9 9 10 11 Carlon 2 gang...
  • Page 73: Further Information

    1.4. Product failures from six (6) months to the end of the warranty period will either be repaired or replaced at the discretion of Lightware. If Lightware chooses to replace the product then the replacement will be warranted for the remainder of the original unit’s warranty period.
