Instrument Specifications

The table found below contains the technical specifications for the Nano ITC instrument.
Table 1: Nano ITC Technical Specifications
Item/Area
Dimensions
Weight
Power
Operating environmental
conditions
Emissions class
Temperature range
Injection interval
Response time
Effective cell volume
Sample volume range
Injection syringe capacity
Volume increment
Stirring rate
Page 16
Specifications
Depth 38 cm (15 in.)
Width 37 cm (14 in.)
Height 32 cm (13 in.)
20 kg (43 lbs)
100–240 VAC, 3 amps. 50–60 Hz
Temperature: 15 to 30°C
Relative Humidity: 5 to 80% (non-condensing)
Installation Category II
Pollution Degree 2
Maximum Altitude: 2500 m (8200 ft)
Class A
2 to 80°C
150 s minimum
15 s
Standard Volume: 1.0 mL (24K gold or Hastelloy)
Low Volume: 190 µL
Standard Volume: 1200 to 1500 µL
Low Volume: 300 to 700 µL
Standard Volume: 100 or 250 µL
Low Volume: 50 µL
0.114% of the total syringe capacity (0.06, 0.11, or 0.29 µL
respectively for the 50, 100, and 250 µL syringes)
150 to 400 rpm
