SUPERIOR SPEED DOME
USER MANUAL
DSC-230SI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSC-230SI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for D-MAX DSC-230SI

Summary of Contents for D-MAX DSC-230SI

  • Page 1 SUPERIOR SPEED DOME USER MANUAL DSC-230SI...
  • Page 3 S U P E R I O R S P E E D D O M E INSTALLATION/OPERATION/PROGRAMMING MANUAL 22X Day / Night Speed Dome Camera...
  • Page 4 WARNING Always have the unit installed by the store it was purchased from. Improper connections and/or installation could result in electrical shock, fire or other serious injury or damage. Do not place the unit on an unstable surface. Always checks the strength and stability of the installation location. A falling unit will result in damage and could cause serious injury.
  • Page 5 CAUTION Always use the unit indoors. The unit should never be used outdoors, or in any place where it will be exposed to rain or other extremes of moisture. Direct exposure to water will result in rust and will damage the unit. Never use in environments that have heavy concentrations of dust, smoke, steam or humidity.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS WELCOME INTRODUCTION OF PRODUCT PRODUCT FEATURES INSTALLING AND CONNECTING WITH EQUIPMENTS NAME AND FUNCTION OF EACH PART 3.1.1 THE NAME OF EACH PART 3.1.2 INSTALLATION AND WIRING CONNECTING WITH EQUIPMENTS 3.2.1 BASIC CONNECTION DIAGRAMS 3.2.2 CONNECTION DIAGRAMS IN DETAIL HOW TO USE FUNCTIONAL DIP SWITCHES 4.1.

  • Page 7: Welcome

    1. WELCOME Thank you for purchasing the integrated speed dome system, Superior Speed Dome. Your new system features a high-resolution, color camera/optics package with Day/Night, DSS technology and programmable dome drive software with OSD menu. This manual is designed to be a reference tool for the installation, operation and programming of your system.

  • Page 8: Introduction Of Product

    2. INTRODUCTION OF THE PRODUCT 2.1 Product Features ☺ ☺ 22x Zoom lens Day & Night function with filter 22x optical zoom lens combined with an auto focus It allows make surveillance in the night or low system and digital zoom enables you to get illumination condition with electronic sensitivity maximum 220x great pictures.

  • Page 9: Installing And Connecting With Equipments

    3. INSTALLING AND CONNECTING WITH EQUIPMENT 3.1 Name and Function of each part 3.1.1 The name of each part A- BACK BOX There is a dome drive in it, connect power cable, data cables and video cable and sensors into it. B- DOME DRIVE It is a dome drive.

  • Page 10: Installation And Wiring

    3.1.2 Installation and wiring (1) Disassembly the camera for installation First, loose the dome drive from the back box. Loose first, the dome drive from the back box. Loose the bolt on the side of cover with a screw driver and it could be removed lower bubble in a way that turn left to lower bubble softly with both hands then pull out it.
  • Page 11 (2) Inside of the back box for installation If you unscrew one of bolt (with ‘+’ screw driver) on the connector Open the connector cover. cover, it is opened Please connect Data, Power and Video cables. Figure 3. Please be careful while connecting as shown below. Plug in one end of (-) RS-485 data cable.
  • Page 12 Did you connect the power cable in normal? If yes, 1) the power is 2) The input power source on, RED LED glows is AC 24V with a terminal which is in the and with a jack. middle of connector. Both of them can be used.

  • Page 13: Connecting With Equipments

    3.2 Connecting with equipments 3.2.1 Basic connection diagrams Using dedicated keyboard controller, it controls and connects a max. 255 of cameras. In the data box of controller, there are two controlling terminal ports and it allows the each terminal port to connect with 128 cameras totally.

  • Page 14: Connection Diagrams In Detail

    3.2.2 Connection diagrams Figure 7. CONNECTION DIAGRAM - Sensor can be connected to a maximum of 4-Channels and if it activates to detect by sensor with PRESET function, automatically the camera moves to the point by PRESET MODE. - Alarm output is a relay switching voltage to be load up to AC/DC24V/0.5A and when it is detected by sensor, it is automatically switching on, can be released through the times or by controller.

  • Page 15: How To Use Functional Dip Switches

    4. HOW TO USE FUNCTIONAL DIP SWITCHES 4.1 Setting DIP switches 4.1.1 Setting optional DIP switches - TERMINATION REGISTER (DIP SWITCH No. 1): This switch allows the end of register to turn on the only last camera of the data lines. If data lines are distributed to several directions, it has to be switched on such camera among the most far away cameras.
  • Page 16 When you set the DIP switch, please set the DIP switch condition of power off firstly then turn on the power. Part A is a power switch. This part can be set up the address for each camera. You can set up the number of camera on the condition of ADDR in Part C.

  • Page 17: Setting Address Dip Switches

    4.1.2 Setting address of DIP Switches Use address setting by DIP switches No. 1 to No. 8, It can be set 1 program to 255 programs. TABLE OF ADDRESS SETTING DIP SWITCH (HEX) DIP SWITCH (HEX) (DEC) (DEC) OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF...

  • Page 18: Setting Baud Rate With Dip Switches

    4.1.3 Setting baud rate with DIP switches These DIP switches allow the user to set data communication baud rate according to the desired protocol. The protocols are selected with 2400 bps, 4800 bps and 9600 bps. Use baud rate for this speed dome with DIP switches as bellows: To program the baud rate, the power switch must be turned off in advance and then after setting of DIP switch, it must be turned on the power.

  • Page 19: Setting Protocols With Dip Switches

    Turn off the power after initializing the protocol and all DIP SW that switched on for programming protocol is switched off again. (DIP SW ‘INIT’ is switched to ‘ADDR’ also.) Set address switches as desire. Turn on the power again. Now it can be operated on desired protocol. The default is D-MAX protocol, 9600 bps.

  • Page 20: How To Operate Your Dome System

    5. HOW TO OPERATE YOUR DOME SYSTEM 5.1 How to operate your dome system How to Control Operation Pan and Tilt Move joystick or press the direction keys left/right (PAN) and up/down (TILT). Zoom Out To zoom out, do the following: 1.

  • Page 21: Accessing Osd Menu

    5.2 Accessing OSD Menu To go for the main menu (OSD Menu) on your monitor: Enter <1> + [MENU] key Programming OSD MENU differs for different types of keyboards. Instructions for programming OSD menu are given below for various dedicated controllers. THE DEDICATED KEYBOARD CONTROLLER 1.

  • Page 22: How To Program Your Dome System

    6. HOW TO PROGRAM YOUR DOME SYSTEM The system information screen displays dome drive model, software version, and <CCTV Transmitter> other diagnostic information. XXX-XXX XXXX Camera : 001 Ver 5.2 System settings cannot be changed using this screen. This screen is for Input? ■...

  • Page 23: Dome Setting

    7. DOME SETTING <View on the monitor> Using the keyboard, it can be opened the OSD menu on the monitor. Enter number <1> and press [MENU] key on the monitor. ◄◄ CAMERA SETUP p1 ►► 1. Set Camera ID : CAM-001 Numeric <1>...

  • Page 24: Sharpness Level

    4. AGC LEVEL ◄◄ CAMERA SETUP p1 ►► AGC (Automatic Gain Control) automatically adjusts the amount of video 1. Set Camera ID : CAM-001 2. ID Display : ON amplification to maintain a full 1-volt peak-to-peak video signal output. 3. Back Light : OFF 4.
  • Page 25 8. FLICKERLESS ◄◄ CAMERA SETUP p1 ►► Flickerless allows remove trembling on the monitor. The shutter speed is 1. Set Camera ID : CAM-001 2. ID Display : ON the time fixed at 1/120 sec for NTSC system, 1/100 sec for PAL system. 3.
  • Page 26 10. WHITE BALANCE ◄◄ CAMERA SETUP p2 ►► This feature automatically processes the viewed the image to retain color 10. White balance : AUTO balance over a color temperature range. The default setting for white balance 11. Focus mode : ONESHOT is AUTO.
  • Page 27 14. MIN DISTANCE ◄◄ CAMERA SETUP p2 ►► Min distance allows adjust camera to make a focus within a minimum 10. White balance : AUTO 11. Focus mode : ONESHOT distance. 12. Zoom Start : x01 To set is with the joystick left / right on the parameter: 13.
  • Page 28 18. AUTO TILT MOVE ◄◄ CAMERA SETUP p3 ►► When the camera tilts downward and goes just beyond the vertical position, 18. Auto Tilt Move : OFF 19. Manual P/T Speed : MEDIUM the dome rotates 180 degrees. When the dome rotates (flips), the camera 20.
  • Page 29 20. PRIVACY ZONE SET ◄◄ CAMERA SETUP p3 ►► 18. Auto Tilt Move : OFF A privacy zone is a pan area, defined by a left and right limit, on the 360- 19. Manual P/T Speed : MEDIUM degree pan plane. The privacy zones are adapted to depth of zoom-in and 20.
  • Page 30 21. ALARM CH ON/OFF PAGE ◄◄ CAMERA SETUP p3 ►► The Superior Speed Dome has four alarm inputs, which can be 18. Auto Tilt Move : OFF 19. Manual P/T Speed : MEDIUM programmed as 0 second to 180 seconds priority. When an alarm is 20.
  • Page 31 22. ALARM PRESET SET PAGE ◄◄ CAMERA SETUP p3 ►► 18. Auto Tilt Move : OFF 19. Manual P/T Speed : MEDIUM ALARM CH PRESET NO. 20. PRIVACY ZONE SET This function allows the user to program alarms with preset positions. 21.
  • Page 32 ALARM MESSAGE (1) CAM-001 This function allows the user to program alarms with the keyboard controller. Save Alarm Set the alarm preset: Save Alarm - The message is appeared on the monitor when it is memorized a related preset number on an activated sensor. It is appeared by means of that is a directly programmed by the CAM-001 keyboard without use OSD menu.
  • Page 33 23. FACTORY RESET PAGE ◄◄ CAMERA SETUP p3 ►► 18. Auto Tilt Move : OFF 19. Manual P/T Speed : MEDIUM This function allows the camera to delete the all programmed data and go 20. PRIVACY ZONE SET back to default status. 21.

  • Page 34: Preset Programming

    8. PRESET PROGRAMMING <View on the monitor> PRESET PROGRAMMING CAM-001 The Superior Speed Dome System allows the user to program preset up to 128-preset positions with the keyboard controller. The following steps are the settings: Set PST01 1. Before setting, position the camera as you desire with the help of joystick.

  • Page 35: Swing Programming

    9. SWING PROGRAMMING <View on the keyboard> SWING PROGRAMMING SET SWING – Before programming the swing, it must be programmed presets. Sw Mode : 1 = Pan, 2 = Tilt Camera : 000 PAN or TILT SWING Input? [MAIN] The following steps are the settings: 1.

  • Page 36: Group Programming

    10. GROUP PROGRAMMING <View on the keyboard> GROUP PROGRAMMING SET GROUP – The ‘Group’ means a group-touring sequence. Group No? 1 - 6 Before programming the group, preset programming must be done. Camera : 000 The one group program allows setting up to maximum 12 presets. Input? [MAIN] The following steps are the settings:...

  • Page 37: Tour Programming

    11. TOUR PROGRAMMING <View on the keyboard> TOUR PROGRAMMING SET TOUR – The ‘Tour’ means an auto-touring sequence. Group No? 1 - 6 Before programming the group, Group programming must be done. Camera : 000 The tour program allows setting up a maximum of 6 –group and 72 presets. Input? [MAIN] The following steps are the settings:...

  • Page 38: Spiral Programming

    12. SPIRAL SEQ PROGRAMMING SPIRAL SEQ PROGRAMMING <View on the monitor> CAM-001 This function allows making spiral surveillance in a way that the camera moves from upper, rotate and slow down sequentially. Spiral SEQ How to run and stop programmed group: RUN –...

  • Page 39: Ptz Trace

    13. PTZ TRACE PROGRAMMING PTZ TRACE PROGRAMMING <View on the keyboard> This function allows memorize pan/tilt/zoom movement for 120 seconds, CCTV Transmitter - play back that trace to memorized movement and repeat again. It is Trace ON / OFF? programmed with the keyboard only. Camera : 000 Input? 8 [MAIN]...

  • Page 40: Error Messages

    14. ERROR MESSAGES ERROR MESSAGES <View on the monitor> Superior Speed Dome system appears error messages in wrong CAM-001 operations as below: CAMERA MODULE ERROR – This error occurs when there is an abnormal communication with the camera module. This CAMERA MODULE ERROR equipment makes reset automatically.

  • Page 41: Trouble Shooting

    15. TROUBLE SHOOTHING 15.1 Caution In Use 1. You must turn off the power switch before installation of this equipment 2. Avoid installation places where it is the ultimate cold, hot, and humid. 3. Use a power supply of AC24V, 1.5Amp output. 4.

  • Page 42: Dimensions

    16. DIMENSIONS Figure 9. INDOOR SPEED DOME...

  • Page 43: Specifications

    17. SPECIFICATIONS Signal System NTSC Total/Effective Pixel 410K / 380K Pixels 470K / 440K Pixels Image Sensor 1/4” SONY COLOR Super HAD CCD H. Resolution More than 480 TVL Minimum Illumination 1.0 Lux (30 IRE) / 0.01 Lux with Sensitive Up Optical Lens 22X Optical Zoom, F=1.6(wide) ~ 3.8(Tele), f= 3.9 ~ 85.8 mm Digital Zoom...

  • Page 44: Quick Starting - Osd Menu Tree

    18. QUICK STARTING – OSD MENU TREE To access OSD menu, enter numeric (1) and press [MENU] button on the keyboard. To shift manu in the menu items, move to joystick up and down. To program the menu parameters, move to joystick left and right. NOTE : if you use DVR or any controller, please ask how to access OSD menu to your supplier.
