Billy Goat HTR1601V Operator Owner's Manual

2 OPTIONAL ACCESSORIES
INTAKE
HOSE KIT TR P/N 810509 Standard on TR
units. [8"(203mm) x 12.5' (3.8m)]
HOSE KIT HTR P/N 810896 Standard on
HTR units. [10"(254mm) x 12.5' (3.8m)]
HOSE COUPLER KIT 8" (203mm) TR
P/N 810525 Quick release coupler joins 2
hoses together to increase vacuuming
distance and allows hoses to be separated
for storage.
HOSE CONNECTOR KIT 8" (203mm) TR
P/N 810524
HOSE CONNECTOR KIT 10" (254mm) HTR
P/N 810776
For permanently connecting 2 hoses together
to increase vacuuming distance .
EXHAUST ALL MODELS
EXHAUST EXTENSION KIT P/N 810637
Increases exhaust height 11"(280mm) for
loading debris into elevated locations.
EXHAUST HOSE KIT P/N 810508
[7"(178mm) x 12.5' (3.8m)] Quick release
coupler and hose increases exhaust distance.
EXHAUST HOSE COUPLER KIT P/N 810506
[7"(178mm)] Quick release coupler joins 2
hoses together to increase vacuuming
distance and allows hoses to be separated for
storage.
EXHAUST HOSE CONNECTOR KIT
P/N 810510 [7"(178mm)] Permanently joins
2 exhaust hoses together to increase
exhaust distance.
PANEL FILTER KIT P/N 810584 Provides air
filter panel for use on truck and trailer
mounted debris enclosures.
PORTABLE DEBRIS BAG P/N 810660
1.3 yds. 3 (1.0m 3 ) or 28.4 bushels (1000L).
For portable use. Several bags can be filled
and left for later pickup.
3
ENGINE: H.P.
ENGINE: WEIGHT
ENGINE: TYPE
ENGINE: FUEL CAPACITY
ENGINE: OIL CAPACITY
UNIT & NOZZLE WEIGHT:
HOSE WEIGHT:
TOTAL WEIGHT (2 cartons): 274 lb (124.3 kg) 299 lb (135.6 kg)
UNIT SIZE:
Part No. 811126
1
Operator Owner's Manual
HTR1601V
16 H.P. TWIN OHV VANGUARD GUARD
79 lbs. (35.83 kg)
Briggs & Stratton 4 Cycle IC Twin
9 qt.(8.52 L),Float feed carb.& fuel pump
1.75 qt. (1.66 L), Oil pump w/filter
UNIT SHIP
247 lb (112 kg) 268 lb (121.6 kg)
27 lb (112.2 kg) 31 lb (14.1 kg)
OVERALL LENGTH: HTR 36.5"(0.93m) / TR 35"(0.89M)
T h a n k Yo u f o r S e l e c t i n g
The Powerful TRUCK LOADER VACUUM
HTR1601V, TR1303H, TR1103

Specifications

TR1303H
13.0 HP (10.68 kW)
68.4 lbs. (31 kg)
HONDA 4 cycle
6.9 qt. (6.0 L)
1.16 qt. (1.1 L)
UNIT SHIP
214.2 lb (97.2 kg) 223.2 lb (101.2 kg) 210 lb (95 kg)
14 lb (6 kg) 23 lb (10 kg)
228.2 lb (103.5 kg) 257.2 lb (116.7 kg) 224 lb (102 kg)
OVERALL WIDTH: 24.25" (0.62m)
Page 1 of 12
TR1103
11.0 HP (9.04 kW)
64.25 lbs. (29.1 kg)
B & S 4 cycle IP
6.0 qt. (5.7 L)
1.5 qt. (1.42 L)
UNIT SHIP
230 lb (104 kg)
14 lb (6 kg) 23 lb (10 kg)
253 lb (115.0 kg)
OVERALL HEIGHT: 44" (1.12m)
Form No. F021602B
