Billy Goat QL2000VE Operator Owner's Manual
  1. Manuals
  2. Brands
  3. Billy Goat Manuals
  4. Lawn and Garden Equipment
  5. QL2000VE
  6. Operator owner's manual
Billy Goat QL2000VE Operator Owner's Manual

Billy Goat QL2000VE Operator Owner's Manual

Ql series truck loader vacuum
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ENGINE: H.P.
ENGINE: WEIGHT
ENGINE: TYPE
ENGINE: FUEL CAPACITY
ENGINE: OIL CAPACITY
ENGINE: MODEL NO.
UNIT WEIGHT:
HOSE W/NOZZLE WEIGHT:
ELBOW WEIGHT:
TOTAL WEIGHT :
BATTERY NOT INCLUDED:
UNIT SIZE (ASSEMBLED W/EXHAUST, NO HOSE):
58"(1.47m) OVERALL WIDTH:
HEIGHT:
74" (1.82m)
Part No. 790161
T h a n k
T h a n k
T h a n k
T h a n k
T h a n k
The Powerful QL Series Truck Loader Vacuum
Operator Owner's Manual

Specifications

QL2000VE
20 H.P.
TWIN OHV VANGUARD
79 lbs. (35.83 kg)
Briggs & Stratton 4 Cycle IC Twin W/electric start
8 qt.(7.57 L), Fuel pump
1.5 qt. (1.4 L), Oil pump w/filter
351447-1171-E1
UNIT
246 lb (111.6 kg)
- - - - - - - - - -
59 lb (26.8 kg)
- - - - - - - - - -
40 lb (18.1 kg)
- - - - - - - - - -
379lb (171.9 kg)
405 lb (185.6 kg)
REQUIRES 12 V BATTERY, 40 AH, 240 CCA MIN.
OVERALL LENGTH:
32" (0.81m)
Y o u
Y o u
Y o u
Y o u
Y o u
f o r
f o r
f o r
f o r
f o r
S e l e c t i n g
S e l e c t i n g
S e l e c t i n g
S e l e c t i n g
S e l e c t i n g
QL2000VE
HOSE REPLACEMENT KIT
Standard on QL units. [12"(305mm) x 10' (3.0m)]
EXHAUST HOSE KIT P/N 790114
SHIP
[8"(203mm) x 5' (1.5m)] Quick release coupler and flexible
steel hose increases exhaust distance.
TRAILER QL
Heavy duty spring axle trailer designed for towing your QL.
OVERALL
Allows unit to be mounted for pickup from rear and both sides.
Page 1 of 12

Optional Accessories

INTAKE
P/N 790211
EXHAUST
TRAILER
P/N 790112
Form No. F032399A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QL2000VE and is the answer not in the manual?

Questions and answers

Related Manuals for Billy Goat QL2000VE

Summary of Contents for Billy Goat QL2000VE

  • Page 1: Optional Accessories

    Operator Owner's Manual QL2000VE QL2000VE 20 H.P. TWIN OHV VANGUARD 79 lbs. (35.83 kg) Briggs & Stratton 4 Cycle IC Twin W/electric start 8 qt.(7.57 L), Fuel pump 1.5 qt.

  • Page 2: Table Of Contents

    IN THE INTEREST OF SAFETY BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL & ENGINE MANUAL.” THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. The engine exhaust from this product contains chemicals known to the State of WARNING! California to cause cancer, birth defects or other reproductive harm.

  • Page 3: General Safety

    PUT OIL IN ENGINE BEFORE STARTING. BATTERY NOT INCLUDED WITH UNIT. Your Billy Goat is shipped from the factory in one carton and is completely assembled except for the exhaust elbow, nozzle, handle loop for nozzle, hose boom, hose band, hose coupler, hose clamps and related hardware.

  • Page 4: Control Panel

    PARTS BAG & LITERATURE ASSY P/N 790111 PARTS BAG ASSEMBLY CHECKLIST P/N 790229 Nut Lock 1/4-20 8160001 Qty. 3 Nut Lock 5/16-18 8160002 Qty. 4 Washer 1/4 SAE 8181008 Qty. 2 Washer 5/16 8171003 Qty. 2 Washer 5/16 SAE 8172008 Qty.

  • Page 5: Operation

    2 illustrates the mounting options available when using the optional trailer (Billy Goat Part no. 790112) available from your Billy Goat dealer. The unit can be mounted to allow vacuuming from either sides as well as from the rear. Trailer tongue Fig.
  • Page 6 OPERATION continued STARTING PUT OIL IN ENGINE BEFORE STARTING. Inspect machine work area and machine before operat- ing. Make sure that all operators of this equipment are trained in general machine use and safety. ENGINE: See engine manufacturer’s instructions for type and amount of oil and gasoline used. Engine must be level when checking and filling oil and gasoline.
  • Page 7 OPERATION ADJUSTING HOSE BOOM: Properly adjusting the boom will prevent most hose clogs from occurring and will maximize vacuum performance by keeping the hose straight and perpendicular to the housing (see fig. 5). Hose Bands. Hose Stretch hose out before clamping.

  • Page 8: Maintenance

    Note: 3/4"-10 x 3" bolt is included in each impeller replacement kit or the bolt can be ordered from your local Billy Goat Dealer (part no. 790214). 8. When impeller is free of the engine shaft, align impeller with the opening and pull it straight out of the housing.

  • Page 9: Maintenance Schedule

    MAINTENANCE continued Maintenance Schedule Maintenance Operation Engine (See Engine Manual) Inspect battery for damage or leak Check battery terminal for corrosion Check for excessive vibration Clean Hose Keep engine free of debris Inspect for loose parts Inspect for worn or damaged parts MAINTENANCE HISTORY Date of Service Hose must be installed and switch...

  • Page 10: Parts Drawing & List

    PARTS DRAWING QL2000VE Part No. 790161 Page 10 of 12 Form No. F032399A...
  • Page 11 ITEM Parts List Part No. 790161 PART DESCRIPTION 400268 LABEL HOT ENGINE 400339 KNOB 400424 LABEL OPEI WARNING 400502 WASHER LOCK 3/8 TWIST 400570 GRIP HANDLE 1" x 13" 500282 STRAIN RELIEF HEYCO 1244 790100 ENGINE 20 HP HORIZ. VANGUARD 790129 LINE FUEL QL 790130...

  • Page 12: Troubleshooting

    Possible Cause Bad or old gasoline. Please fill in the WARRANTY CARD and send the upper part to Billy Goat. The WARRANTY terms are stated on the lower part which remains with the user. Whenever a Billy Goat Machine is faulty due to a defect in material...

Table of Contents

Save PDF
