VC70B-KU Installation Guide
• 1 VC70B-KU system unit
• 4 Mounting screws for Mini PCIe module
• 1 Quick Installation Guide
• 1 Disk includes:
- Drivers / Manual
Note:
The CD that came with the system contains an autorun screen to install drivers, utilities,
and software applications required to enhance the performance of the system and a user's
manual for your reference. Insert the CD into a CD-ROM drive. The autorun screen will
appear. If after inserting the CD, "Autorun" did not automatically start, please go directly to
the root directory of the CD and double-click "Setup". Please install all required drivers.
DFI reserves the right to change the specifications at any time prior to the product's release. For the latest revision and details of the
installation process, please refer to the user's manual.

Package Contents

www.dfi.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC70B-KU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DFI VC70B-KU

  • Page 1 CD and double-click “Setup”. Please install all required drivers. DFI reserves the right to change the specifications at any time prior to the product's release. For the latest revision and details of the installation process, please refer to the user's manual.
  • Page 2 Panel Status LED (Blue) COM 1 COM 2 HDD LED Power button (Green LED) Front View Reset COM 6 COM 4/ 8-bit DIO COM 5 CANbus* LAN 2 LAN 1 HDMI USB 3.0 COM 3 (RS232/RS422/RS485) Line-out Mic-in Rear View DC-in Antenna hole...
  • Page 3 Removing the Chassis Cover Please observe the following guidelines and follow the procedure to open the system. 1. Make sure the system and all other peripheral devices connected to it have been powered off. 2. Disconnect all power cords and cables. 3.
  • Page 4 Installing a Mini PCIe Card The system board is equipped with 2 Mini PCIe slots: one full-size and one half- size slot. Here we will demonstrate the installation of a full-size Mini PCIe card. The Mini PCIe sockets are located on the main board; to access the main board, detach the power board on top of it.
  • Page 5 10-11 On (default) Auto-PWR ON 2-3 On 2-3, 5-6, 8-9, 11-12 On Mini PCIe/SATA Select PCIe 2-3 On SATA 1-2 On (default) Note: You cannot use COM 4 and DIO at the same time. Please adjust JP1 and JP2 together. www.dfi.com...
  • Page 6 Please make sure that system-off delay time is sufficient to allow the OS to shut down completely. Please do not alter the SW1-1 (should be "ON") setting to prevent damage to the system board. Please do not push the power button during system startup or shutdown. www.dfi.com A52701903...
