Quick Installation Guide
VC900-M8M
1 x VC900-M8M system unit
1 x 3-pole terminal block cable for power input
1 x Wall mount bracket/screw pack
1 x Quick installation guide
© April 13, 2023 DFI Inc.
Package Contents
www.dfi.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC900-M8M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DFI VC900-M8M

  • Page 1 Quick Installation Guide VC900-M8M www.dfi.com Package Contents 1 x VC900-M8M system unit 1 x 3-pole terminal block cable for power input 1 x Wall mount bracket/screw pack 1 x Quick installation guide © April 13, 2023 DFI Inc.
  • Page 2: Product Overview

    Product Overview Front I/O view USB 3.0 Power Input COM 1 Reset Button HDMI CAN BUS Status LED Quick Installation Guide | VC900-M8M...
  • Page 3 Side I/O view COM 4 COM 2 COM 3 Quick Installation Guide | VC900-M8M...
  • Page 4: Removing The Chassis Cover

    Step 2: Slide the cover to open the system. Step 3: The boards can be easily accessed after the chassis cover is removed. System Board Power Board Quick Installation Guide | VC900-M8M...
  • Page 5: Installing An M.2 Card

    Installing an M.2 Card M.2 Sockets Quick Installation Guide | VC900-M8M...
  • Page 6 Screw tight the card onto the stand-off with a screw driver and a stand-off screw until the gap between the card and the stand-off closes up. The card should be lying parallel to the board when it’s correctly mounted. Quick Installation Guide | VC900-M8M...
  • Page 7: Installing An Antenna

    Connect the internal cable to the board's antenna connector, screw the antenna connector through the antenna hole with washers and nuts, and screw on the antenna as illustrated below. Antenna Chassis Wall Module Connector Cable Antenna Connector Washer Quick Installation Guide | VC900-M8M...
  • Page 8: Jumper Settings

    Power Board Power Board ST-Link / SWD MCU Debug Remote Switch Remote Switch High/Low Active 12V DC Out 9V~36V In Host Bus Communication Host Bus Communication LED1(Red): Debug LED for the MCU LED2 (Green): R/W LED Quick Installation Guide | VC900-M8M...
  • Page 9 10 minutes 6 On , 7 On, 8 Off 15 minutes 6 Off , 7 On, 8 Off 30 minutes 6 On , 7 Off, 8 Off 1 hour 6 Off , 7 Off, 8 Off Quick Installation Guide | VC900-M8M...
  • Page 10 Power Board System Board USB2_4 HDMI Battery Power Link SIM Slot USB3.0 DC-IN Audio Speaker M.2 B key USB2_3 M.2 E key VP IO COM1 Debug Boot CFG LVDS LED Backlight Quick Installation Guide | VC900-M8M...
  • Page 11 5-6 On Backlight Power 5V 4-6 On DFI reserves the right to change the specifications at any time prior to the product's release. This QR may be based on the product’s revision. For more documentation and drivers, please visit the download page at www.dfi.com/...
