LED Indicators

LED Indicator
PWR/ Green
HDD/ Blue
PL1/ Green
PL2/ Green
3.1.5

DC Power Input Connector

The DC-in connector has three pins as shown in the table below.
Pin Marine/ Railway
1
2
3
The DC-in power input connector is an M12 A-code Male 5-pin connector.
Pin
1
2
3
4
5 Chassis GND
The PoE Power in connector has four pins as shown in the table below (W/ PSU-120)
Pin
1
2
3
4
Connector
Function
Power on
HDD activity
Programmable
Programmable
+
-
NC
Signal
VCC
VCC
System GND
System GND
PoE Power
VCC
System GND
NC
NC
