3. Introduction to Extended Relay Card MCB
113

3.1.3. Electrical Data

Relays:
Number
Load at 250 V AC / 30 V DC
Load at 250 V AC / 30 V DC with cos φ = 0.4
Overvoltage category (contact-earth)
Overvoltage category (contact-contact)
3
Combination of 250 V and 24 V signals
Digital Inputs:
Number
Range
Mode
Input impedance
Low trigger level
High trigger level
Analog Outputs:
Number
Range
Resolution
Linearity
EMC
EMC
8
IEC 61000-6-2 and IEC 61800-3 regarding Immunity of BURST, ESD, SURGE and Conducted Immunity
MI.33.G2.02 - VLT® is a registered Danfoss trademark
FC 300 Extended Relay Card Operating In-
Possible with one unused relay in-between
structions
4 SPDT
8 A
3.5 A
III
II
7
0/24 V
PNP/NPN
4 kΩ
6.4 V
17 V
2
0/4 -20 mA
11 bit
< 0.2%
