5. Parameter Set-up
Preset ramp bit
Ramp 1
Ramp 2
Ramp 3
Ramp 4
[36] Mains failure inverse
[41] Latched Precise Stop inverse
[55] DigiPot Increase
[56] DigiPot Decrease
[57] DigiPot Clear
[60] Counter A
5
[61] Counter A
[62] Reset Counter A
[63] Counter B
[64] Counter B
[65] Reset Counter B
[70] Mech. Brake Feedback
[71] Mech. Brake Feedback inv.
[80] PTC Card 1
5-20 Terminal X46/1 Digital Input (MCB 113)
Option:
[0] * No operation
5-21 Terminal X46/3 Digital Input
Option:
[0] * No operation
5-22 Terminal X46/5 Digital Input
Option:
[0] * No operation
5-23 Terminal X46/7 Digital Input
Option:
[0] * No operation
5-24 Terminal X46/9 Digital Input
Option:
[0] * No operation
5-25 Terminal X46/11 Digital Input
Option:
[0] * No operation
14
Activates par. SP-10 Line failure . Mains failure inverse is active in the Logic .0. situation.
Sends a latched stop signal when the precise stop function is activated in par. H-83 Precise
Function
. The Latched Precise stop inverse function is available for terminals 18 or 19.
INCREASE signal to the Digital Potentiometer function described in parameter group 3-9*
DECREASE signal to the Digital Potentiometer function described in parameter group 3-9*
Clears the Digital Potentiometer reference described in parameter group 3-9*
(Terminal 29 or 33 only) Input for increment counting in the SLC counter.
(Terminal 29 or 33 only) Input for decrement counting in the SLC counter.
Input for reset of counter A.
(Terminal 29 or 33 only) Input for increment counting in the SLC counter.
(Terminal 29 or 33 only) Input for decrement counting in the SLC counter.
Input for reset of counter B.
Brake feedback for hoisting applications
Inverted brake feedback for hoisting applications
All Digital Inputs can be set to PTC Card 1 [80]. However, only one Digital Input must be set to this
choice.
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter.
Follow the function stated in 5-1*
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter.
Follow the function stated in 5-1*
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter.
Follow the function stated in 5-1*
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter.
Follow the function stated in 5-1*
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter.
Follow the function stated in 5-1*
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter.
Follow the function stated in 5-1*
MI.33.G2.02 - VLT® is a registered Danfoss trademark
FC 300 Extended Relay Card Operating In-
1 0
0 0
0 1
1 0
1 1
structions
Stop
