FC 300 Extended Relay Card Operating In-
structions
5-26 Terminal X46/13 Digital Input
Option:
[0] * No operation
5.2.2. 5-3* Digital Outputs
Parameters for configuring the output functions for the output terminals. The 2 solid-state digital outputs are common for terminals 27 and 29. Set the
I/O function for terminal 27 in par. E-51 Terminal
cannot be adjusted while the motor is running.
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready / remote control
[4] Enable / no warning
[5] VLT running
[6] Running / no warning
[7] Run in range / no warning
[8] Run on reference / no warning
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedback range
[19] Below feedback low
[20] Above feedback high
[21] Thermal warning
[22] Ready, no thermal warning
[23] Remote, ready, no thermal warning
[24] Ready, no over-/ under voltage
[25] Reverse
[26] Bus OK
[27] Torque limit and stop
[28] Brake, no brake warning
[29] Brake ready, no fault
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter.
Follow the function stated in 5-1*
27 Mode
, and set the I/O function for terminal 29 in par. E-52 Terminal
Default for all digital outputs and relay outputs
The control board receives supply voltage.
The frequency converter is ready for operation and applies a supply signal on the control board.
The frequency converter is ready for operation and is in Auto On mode.
Ready for operation. No start or stop command is been given (start/disable). There are no warnings.
Motor is running.
Output speed is higher than the speed set in par. H-81 Min
motor is running and there are no warnings.
Motor is running within the programmed current and speed ranges set in par. H-70 Warning
Low to par. H-73 Warning Speed High
Motor runs at reference speed.
An alarm activates the output. There are no warnings.
An alarm or a warning activates the output.
The torque limit set in par. F-40 Torque
The motor current is outside the range set in par. F-43 Current
Motor current is lower than set in par. H-70 Warning
Motor current is higher than set in par. H-71 Warning
Output frequency is outside the frequency range set in par. H-70 Warning
Current High
H-71 Warning .
Output speed is lower than the setting in par. H-72 Warning
Output speed is higher than the setting in par. H-73 Warning
Feedback is outside the range set in par. H-76 Warning
Feedback High
ing .
Feedback is below the limit set in par. H-76 Warning
Feedback is above the limit set in par. H-77 Warning
The thermal warning turns on when the temperature exceeds the limit in the motor, the frequency
converter, the brake resistor, or the thermistor.
Frequency converter is ready for operation and there is no over-temperature warning.
Frequency converter is ready for operation and is in Auto On mode. There is no over-temperature
warning.
Frequency converter is ready for operation and the mains voltage is within the specified voltage
General Specifications
range (see section).
Reversing. Logic '1' when CW rotation of the motor. Logic '0' when CCW rotation of the motor. If
the motor is not rotating the output will follow the reference.
Active communication (no time-out) via the serial communication port.
Use in performing a coasting stop and in torque limit condition. If the frequency converter has
received a stop signal and is at the torque limit, the signal is Logic '0'.
Brake is active and there are no warnings.
Brake is ready for operation and there are no faults.
MI.33.G2.02 - VLT® is a registered Danfoss trademark
29 Mode
Speed for Function at Stop [RPM]
. There are no warnings.
Limiter (Driving)
or par. 1-17 has been exceeded.
Limit
.
Current Low .
Current High
.
Speed Low
.
Speed High .
Feedback Low
Feedback Low
.
Feedback High .
5. Parameter Set-up
. These parameters
5
. The
Current
Current Low
and par.
and par. H-77 Warn-
