FC 300 Extended Relay Card Operating In-
structions

3.1.3 Galvanic Isolation

MCB 113 can be connected to an external 24 V on X58/ in order to ensure galvanic isolation between the VLT AutomationDrive and the option card. If
galvanic isolation is not needed, the option card can be supplied through internal 24 V from the frequency converter - available on X58/ provided that
internal supply is specified in par. 14-80
The relays support a combination of 24 V and 250 V signals as long as there is an unused relay in-between.

3.1.4 Electrical Data

Relays:
Number
Load at 250 V AC / 30 V DC
Load at 250 V AC / 30 V DC with cos φ = 0.4
Overvoltage category (contact-earth)
Overvoltage category (contact-contact)
Combination of 250 V and 24 V signals
Digital Inputs:
Number
Range
Mode
Input impedance
Low trigger level
High trigger level
Analog Outputs:
Number
Range
Resolution
Linearity
EMC
EMC

3.1.5 Ordering Numbers

130B1164 (Non-coated)
130B1264 (Coated)
Option Supplied by External 24VDC ([0] No).
IEC 61000-6-2 and IEC 61800-3 regarding Immunity of BURST, ESD, SURGE and Conducted Immunity
MI.33.G3.02 - VLT® is a registered Danfoss trademark
3 Introduction to Extended Relay Card MCB
Possible with one unused relay in-between
113
3
4 SPDT
8 A
3.5 A
III
II
7
0/24 V
PNP/NPN
4 kΩ
6.4 V
17 V
2
0/4 -20 mA
11 bit
< 0.2%
9
