TM 700 DN
Electronic Drive Unit
Operating Instructions
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TM 700 DN and is the answer not in the manual?

Questions and answers

Related Manuals for Pfeiffer Vacuum TM 700 DN

Summary of Contents for Pfeiffer Vacuum TM 700 DN

  • Page 1 TM 700 DN Electronic Drive Unit Operating Instructions...

  • Page 2: Table Of Contents

    6.5 DeviceNet objects ......... . . 16 The Pfeiffer Vacuum parameter set ....... . 25 7.1 General .

  • Page 3: About This Manual

    1 About this manual 1.1 Validity This operating manual is for customers of Pfeiffer Vacuum. It describes the functioning of the designated product and provides the most important information for safe use of the unit. The description follows applicable EU guidelines. All information provided in this operating manual refer to the current state of the product's development.

  • Page 4: Safety

    ● Power supply: The turbopump power supply must apply to the requirements of dou- ble insulation between mains input voltage and operating voltage according to the reg- ulations of IEC 61010 and IEC 60950. Therefore Pfeiffer Vacuum recommends to use exclusively original-power packs and -accessories. Only in this case Pfeiffer Vacuum is able to guarantee the compliance of the European and North American guidelines.

  • Page 5: Proper Use

    EU directives and reassess it accord- ingly. ● The electronic drive unit TM 700 DN operates designated Pfeiffer Vacuum turbo- pumps and their accessories in a DeviceNet bus system. 2.3 Improper use Improper use will cause all claims for liability and warranties to be forfeited.

  • Page 6: Product Description

    For information about other certifications, if applicable, please see the signet on the prod- uct or: ● www.tuvdotcom.com ● TUVdotCOM-ID 0000021320 The electronic drive unit TM 700 DN is an integrated component of the turbopump. It's Product features purpose is to drive, monitor and control the entire pump. Characteristics...

  • Page 7: Function

    M12 socket with screw coupling for the connection of Pfeiffer Vacuum accessories. The use of a Y-connector enables double assignment of one connection. PV.can M12 casing socket with screw coupling and LED for Pfeiffer Vacuum Service pur- poses. remote High Density D-sub 26 pole female socket for the connection of a remote control.

  • Page 8: Connections Diagram

    Relay 2 + U B (+24 / +48 VDC ± 5 %) Relay 2 Relay 2 Relay 3 Relay 3 DO Remote priority active RS485 D+ RS485 D- GND* Fig. 2: Connections diagram and assignment of the TM 700 DN...

  • Page 9: Connection "Remote

    = 1 A) DO Remote priority GND: off; V+: remote priority active RS-485 D+ according to specifications and Pfeiffer Vacuum protocol RS-485 D- according to specifications and Pfeiffer Vacuum protocol Ground (GND) Reference ground for all digital inputs and all outputs...

  • Page 10: Operation Via "Remote" Connection

    The digital inputs at connection "remote" are used to connect various functions of the Inputs electronic drive unit. Functions are assigned to the inputs DI1 - DI2 ex factory. These can be configured via interface RS-485 and the Pfeiffer Vacuum parameter set. DI1 (Enable venting) / Pin 2 V+ :...
  • Page 11 Remote priority inactive AI Rotation speed setting mode / Pin 7 and Pin 11 The analog input at the TM 700 DN defines the set rotation speed of the turbopump. An f(%) input signal of 2 - 10 V between AI+ (Pin 7) and AI- (Pin 11) corresponds to a rotation speed within the range of 20 - 100% of the nominal rotation speed.
  • Page 12 3 is inactive. The contact between Pin 21 and Pin 22 is open when a warning mes- sage is present; relay 3 is active. One Pfeiffer Vacuum display and control panel (DCU or HPU) or an external PC can be RS-485 connected respectively to the electronic drive unit via Pin 24 and Pin 25 of the connec- tion "remote"...

  • Page 13: Connection "Devicenet

     Perform DeviceNet wiring in accordance with the applicable specifications.  Supply the DeviceNet connection with voltage. 6.2 Configuring the connection To start DeviceNet communication, the TM 700 DN must be configured using the en- closed EDS files.  Select desired device address ...

  • Page 14: Configuring The Data Exchange

    Connection "DeviceNet" The DeviceNet baud rate is set manually using the "RATE" selector switches or via De- Baud rate viceNet. Position Meaning RATE 125 kBit/s 250 kBit/s 500 kBit/s Baud rate via DeviceNet Setting the baud rate manually  Set the selector switches to the desired value. –...
  • Page 15 Connection "DeviceNet" For the cyclical data exchange, multiple DeviceNet objects are combined to form assem- Cyclical data ex- blies (4.x.3.). One assembly is selected for each direction (input/output data). The follow- change (poll I/O con- ing assemblies are available for selection: nection) Input data (produced data, pump -->...

  • Page 16: Led Operation

    USINT Minor Revision USINT 1.1.5 Status WORD 1.1.6 Serial Number UDINT 1.1.7 Product Name SHORT_STRING get TM 700 DN 1.1.100 Status Code SHORT_STRING get This object provides no attributes and services. Message Router DeviceNet Path Name Data type Service Comment 3.0.1...
  • Page 17 Connection "DeviceNet" Assembly Path Name Data type Service Comment 4.0.1 Revision UINT 4.0.3 Number of Instances UINT 4.0.100 Poll I/O Input Data USINT get, (set) Assembly instance for input data (pump->master) of Poll I/O con- nection, set only if connection not active 4.0.101 Poll I/O Output Data...
  • Page 18 Connection "DeviceNet" Instance 103 (output): pump/speed control, set speed, vent valve cfg Vent Valve Cfg. (2) BYTE 7.1.4 (2) Connection Path Name Data type Service Comment 5.0.1 Revision UINT Instance 1: Explicit connection 5.1.1 State USINT 5.1.2 Instance Type USINT 5.1.3 Transport Class Trigger BYTE 5.1.4...
  • Page 19 Connection "DeviceNet" Register Path Name Data type Service Comment 7.0.1 Revision UINT 7.0.2 Max Instance UINT 7.0.3 Number of Instances UINT Instance 1 7.1.1 Bad Flag BOOL 7.1.2 Direction BOOL 7.1.3 Size UINT 7.1.4 Data ARRAY of get, set BITS –...
  • Page 20 Connection "DeviceNet" Instance 100: Brake 9.100.3 Value BOOL get, set – 0: Brake off – 1: Brake released 9.100.5 Fault Action BOOL get, set – 0: Brake off – 1: Hold last state 9.100.6 Fault Action BOOL get, set 9.100.7 Idle Action BOOL get, set...
  • Page 21 Connection "DeviceNet" S-Device Supervisor Path Name Data type Service Comment 48.0.1 Revision UINT 48.0.2 Max Instance UINT 48.0.3 Number of Instances UINT Instance 1 48.1.0 (Instance) res, sta, abo, rec, 48.1.3 Device Type SHORT_STRING get 48.1.4 SEMI Standard Revi- SHORT_STRING get sion Level 48.1.5 Manufacturer’s Name...
  • Page 22 Connection "DeviceNet" Bit Common Ex. Detail 0 Common Ex. Detail 1 Device Ex. Detail 0 Device Ex. Detail 1 internal diagnostic Excess supply Drive unit Motor excess tempera- ture Microcontroller reserved Pump excess temper- ature EPROM Output voltage supply Voltage supply Bearing excess tem- perature EEPROM...
  • Page 23 Connection "DeviceNet" Instance 2: RS485 101.2.19 Address USINT get, set 1-255: RS485 address Instance 4: Remote 101.4.17 Configuration USINT get, set {0;4} (see p. 30, chap. 7.3) Instance 6: DI1 101.6.17 Configuration USINT get, set 0-5(see p. 30, chap. 7.3) Instance 7: DI2 101.7.17 Configuration...
  • Page 24 Connection "DeviceNet" Data types Data type Byte Description Example BOOL Binary value (0/1) 00h: 0, 01h:1 BYTE 8 single bits 00h, FFh DINT signed integer 12345678h: 89h, 56h, 34h, 12h signed integer 1234h: 34h, 12h Packed EPATH 1.2.3: 20h, 01h, 24h, 02h, 30h, 03h SHORT_STRIN character string with antecedent "Bilbo": 05h, 42h, 69h, 6Ch, 62h, 6Fh...

  • Page 25: The Pfeiffer Vacuum Parameter Set

    All function-relevant variables of a turbopump are anchored in the electronic drive unit as parameters. Each parameter has a three-digit number and a designation. Parameters can be used via Pfeiffer Vacuum display and control units or via RS-485 with the Pfeiffer Vacuum protocol.
  • Page 26 The Pfeiffer Vacuum parameter set Control commands default  Display Designation Functions Unit min max 001 Heating Heating 0 = off 1 = on 002 Standby Standby 0 = off 1 = on 004 RUTimeCtrl Run-up time control 0 = off...
  • Page 27 The Pfeiffer Vacuum parameter set default  Display Designation Functions Unit min max 036 Cfg Acc B1 Configuration accessory connection B1 0 = Fan (continous operation) 1 = Venting valve, normally closed 2 = Heating 3 = Backing pump 4 = Fan (temperature controlled)
  • Page 28 The Pfeiffer Vacuum parameter set default  Display Designation Functions Unit min max 047 Cfg Rel R3 Configuration Relay 3 0 = Rot. speed switch point attained 1 = No error 2 = Error 3 = Warning 4 = Error and/or warning...
  • Page 29 The Pfeiffer Vacuum parameter set default  Display Designation Functions Unit min max PumpAccel Pump accelerates 0 = no 1 = yes SetRotSpd Set rotation speed (Hz) 999999 ActualSpd Active rotation speed (Hz) 999999 DrvCurrent Drive current 9999.99 OpHrsPump Operating hours pump...

  • Page 30: Configuring The Connections

    The Pfeiffer Vacuum parameter set 7.3 Configuring the connections The electronic drive unit is pre-configured in the factory. Thereby the turbopump is im- mediately operational with the necessary functions. The connections of the electronic drive unit can be configured to suit individual requirements using the parameter set.

  • Page 31: Operation With The Pfeiffer Vacuum Parameter Set

    Interface selection via [P:060] 1 = on Interface selection locked 7.4 Operation with the Pfeiffer Vacuum parameter set The electronic drive unit is pre-programmed in the factory. This guarantees proper, reli- Factory settings able turbopump operation without the need for additional configuration.
  • Page 32  Ensure the gas mode is correctly set.  Contact Pfeiffer Vacuum before using gases with a greater molecular mass (> 80). ● Gas mode "0" for gases with the molecular mass >39, e.g. Ar. ● Gas mode "1" for gases with the molecular mass ≤ 39.
  • Page 33 The Pfeiffer Vacuum parameter set The rotation speed switch point can be used for the message "Pump operational for the Adjusting the rotation process". Overrunning or underrunning the active rotation speed switch point activates speed switchpoint or deactivates a signal at the pre-configured output on the electronic drive unit and at the status parameter [P:302].
  • Page 34  Adjust the parameter [P:707] to the desired value in %.  Parameter [P:026] = 1  Read the parameters [P:308]/[P:397]. Pfeiffer Vacuum recommends standby mode for the turbopump during process and pro- Standby duction stops. When standby mode is active, the electronic drive unit reduces the rotation speed of the turbopump.
  • Page 35 Pfeiffer Vacuum recommends the intermittend mode between 5 and 10 mbar. A pressure gauge and a dosing valve are required to set the switching thresholds.
  • Page 36 Balance ance is expressed as a percentage of the maximum possible rotor imbalance due to the drive electronics and can be viewed via the RS-485 interface using the Pfeiffer Vacuum display and control unit or PC.  Display the current rotor balance in % via parameter [P:329].

  • Page 37: Switching On/Off The Pump

    The Pfeiffer Vacuum parameter set – Operation of the pump is no longer possible. – Please contact Pfeiffer Vacuum Service. If threshold values are overrun, output signals from temperature sensors allow the pump Monitoring the ther- to be brought to a safe condition. Depending on pump type, temperature threshold val- mal load ues for warnings and error messages are saved fixed in the electronic drive unit .

  • Page 38: Pfeiffer Vacuum Protocol For "Rs-485

    Pfeiffer Vacuum Protocol for "RS-485" 8 Pfeiffer Vacuum Protocol for "RS-485" 8.1 Telegram frame The telegram frame of the Pfeiffer Vacuum protocol contains only ASCII code characters [32; 127], the exception being the end character of the message . Basically, a master ...

  • Page 39: Applied Data Types

    Pfeiffer Vacuum Protocol for "RS-485" Example 2 Control command Switch on pumping station (parameter [P:010], device address slave: "042") ! ASCII Control command understood Switch on pumping station (parameter [P:010], device address slave: "042") ! ASCII 8.3 Applied data types...

  • Page 40: Malfunctions

    Problem Possible cause Remedy code Err001 Excess rotation speed  Contact Pfeiffer Vacuum Service  Reset at rotation speed f = 0 only Err002 Overvoltage – Wrong mains pack used  Check type of mains pack  Check mains pack voltage Err006 Run-up time error –...
  • Page 41 Problem Possible cause Remedy code Err046 Internal initialization fault  Contact Pfeiffer Vacuum Service Err073 Overload axial bearing  Contact Pfeiffer Vacuum Service Err074 Overload radial bearing  Contact Pfeiffer Vacuum Service Err089 Rotor out of target area, stabilization im- –...

  • Page 42: Declaration Of Conformity

    We hereby certify, that the product specified below is in accordance with the provision of EU Electromagnetic Compatibility Directive 2004/108/EEC and EU Low Voltage Di- rective 2006/95/EEC. TM 700 DN Guidelines, harmonised standards and national standards and specifications which have been applied:...
  • Page 44 Pfeiffer Vacuum stands for innovative and custom Leading. Dependable. Customer Friendly vacuum solutions worldwide. For German engineering art, competent advice and reliable services. Ever since the invention of the turbopump, we´ve been setting standards in our industry. And this claim to leadership will continue to drive us in the future.
