Advantech AIMC-3421 Startup Manual

AIMC-3421
Micro Computer, Intel® Core™ i7/i5/i3 CPU, H81,
4 Expansions, 300W PSU
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. AIMC-3421 Bare System x 1
2. Driver CD x 1
3. USB 2.0 Cable x 1
4. USB 3.0 Cable x 1
5. Four-port USB Cable x 1
6. LPT Cable x 1
7. Mounting Brackets x 2
8. Rubber Foot x 4
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: For detailed contents of AIMC-3421, please refer
to information on the enclosed CD-ROM (in PDF
format).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the AIMC-3421 Series Rev. A1.
Part No. 2001342101
Printed in China
P/N: AIMC-3421-00A1E
(AIMC-3421-03A1E)
P/N: 2066302801
P/N: 1700014398
P/N: 1700020277-01
P/N: 1700014398
P/N: 1700002223
P/N: 1960014487T00C
P/N: 1990012452S000
2nd Edition,
May 2015
Specifications
Processor System
• LGA1150 Intel Core™ i5/i3/Pentium
®
Haswell Refresh CPU (Support from BIOS V2.XX)
CPU i7-4790S i5-4590S
Base Frequency (GHz) 3.2 3
L3 Cache (MB) 8 6
Haswell CPU (Support from BIOS V1.XX)
i7- i7- i5- i5-
CPU
4770S 4770TE 4570S 4570TE
Base
Frequency 3.1 2.3 2.9 2.7
(GHz)
L3 Cache
8 8 6 4
(MB)
* Part Number iX-XXXXTX & GXXXXXX can use 1U CPU
Cooler for 2 Expansion slots. The rest CPUs have to use
1.5U Cooler for 1 Expansion slot.
BIOS
• AMI 128 Mbit SPI Flash
Chipset
• Intel H81
Memory
• Supports Dual Channel DDR3 1066/1333/1600 8 GB per
DIMM, Max capacity is 16GB
Graphic
• Chipset: Intel HD Graphics
®

Expansion Slot

• AIMC-3421-00A1E:
- One PCIe x16
- One PCIe x4
- Two PCI
• AIMC-3421-03A1E:
- One PCIe x16
- Three PCI
Ethernet
• Chipset supports:
- LAN 1: Intel® I217V
- LAN 2: Intel® I211
• Connection:: 2 on-board RJ-45 connector with LED
indicators
SATA
• Max Data Transfer Rate: 600 MB/s (SATA 3.0)
• HDD Bay: 1 internal 3.5"
AIMC-3421 Startup Manual 1
/Celeron
® ®
i5-4590T i3-4360 i3-4350T
2 3.7 3.1
6 4 4
i3- i3-
G3420 G3320TE G1820 G1820TE
4330 4330TE
3.5 2.4 3.2 2.3 2.7
3 3 3 3 2
i3-4340TE
2.6
4
2.2
2
