- Page 1 AIMB-723 4U CPU Cooler Installation SOP Ming.Cheng, AE IASG IIOT, Advantech...
- Page 2 Required mounting parts...
- Page 3 Attaching the mounting bars First, put the plastic spacers onto the screw threads of the backplate, the fix the mounting bars using the four lone screws.
- Page 4 Applying the thermal paste If there are residual traces of thermal paste or thermal pads on your CPU, please clean them off first. Apply 5 small dots; 4 small dots near the corners plus 1 dot in the centre.
- Page 5 Fastening the heatsink to the CPU First, take off the fan as well as the protection cover at the bottom side of the heatsink. Then put the heatsink onto the CPU and screw it to the two screw threads of the mounting bars. Caution, the direction of the screw hole.
-
Page 6: Fan Setup
Fan setup Caution, two fans direction diagrams need to be in the same direction, and the air flow must be directed to the IO port. - Page 7 Fan setup Follow three step, reattach two fans using the supplied fan clips.
- Page 8 Fan setup Connect two fans connector to Y-cable, and Fan1 to Cable1, Fan2 to Cable2. Cable2 Cable1 Fan1 Fan2 Cable1 Cable2...
- Page 9 Fan setup Connect Y-cable to the Motherboard CPU FAN1 connector.
- Page 10 Remove/Change CPU Please follow page 9 to 3, and remove the right mounting bar to remove or change CPU.
- Page 11 Co-Creating the Future Co-Creating the Future of the IoT World of the IoT World...
