Combifast® -
Maintenance original instructions

3 TECHNICAL FEATURES

Technical specifications
MOVABLE component
Milk Line (IDxOD)
Vacuum Line (IDxOD)
Dimensions (LxWxH)
Weight
FIXED component
Milk Line
Diameter stainless steel milk tube
opening
Diameter vacuum tube opening
Vacuum Connector (IDxOD)
Dimensions (LxWxH)
Weight
Operation specifications
Operating vacuum
Operating temperatures
(environment)
Transport/storage temperatures
Temperature of the washing
mixture

4 FORESEEN AND UNFORESEEN USE

4.1 Foreseen use

®
CombiFast is a connecting system designed to simultaneously connect milk, vacuum, electrical power
supply and data transfer lines.
Suitable for any round-the-shed milking system, CombiFast
iMilk401, iMilk401 Lite and Acr Smart. They allow pulsation control, measurement of milk extracted (only with
Portable iMilk401 and iMilk401 Lite) and automatic cluster removal
NOTE
For further information see chapter

4.2 Unforeseen use

The machinery, as outlined in this manual, must not be used for purposes other than those foreseen and
indicated in the 4.1 - Foreseen Use
WARNING
Any use other than the one covered in this manual is considered improper use and is
therefore forbidden. InterPuls S.p.A. declines any liability associated with any use of the
device other than the one covered in this manual.
WARNING
Application of loads is forbidden.
THIS MANUAL IS THE PROPERTY OF -
Instruction Manual, Operation
16x18 mm (0.63x0.7 in)
14x19 mm (0.55x0.74 in)
240x240x89 mm (9.44x9.44x3.5 in)
0.146 Kg (0.32 lb)
OD 40 – 50,8 – 52 – 63
22 mm (0.86 in)
22 mm (0.86 in)
14x19 mm (0.55x0.74 in)
173 x 148 x 102 mm (6.81x5.82x4.01 in)
0.506 kg (1.11 lb)
between 36 and 60kPa (typically 50kPa)
between 10.63 and 17.71 "Hg (typically 14.76 "Hg)
-5ºC ÷ +40ºC (23°F ÷ 104°F)
-20ºC ÷ +50ºC (-4°F ÷ 122°F)
Min 60°C - Max 90°C (Min 140°F – Max 194°F)
6 - COMBIFAST WITH
section.
InterPuls S.p.A.
and
1420066_02.17_EN
®
can be used in conjunction with Portable
PORTABLE.
-
