Hyundai HYMT5200 User Manual page 20

3.47 Tighten the hand wheel to lock the attachment in to place.
HARNESS
3.48 Place the harness over your head ensuring that the shoulder pads sit comfortably
on your shoulders.
3.49 Push the buckle together until you hear it click in to place.
3.50 The harness can be adjusted at multiple point, to adjust the harness pull on the tabs
until it fits you comfortably giving an even weight distribution.
3.51 Place the thigh protector on the right hand side of your body to provide protection
from the machine.
3.52 Clip the harness to the harness point on the main shaft.
3.53 Loosen the bolt on the harness point and move it up and down the shaft until you find a
comfortable working position, then secure tightly.
20
