GRASS TRIMMER
NOTE
The threaded shaft on the trimmer/brush cutter head is a left handed thread.
3.6 Attach the trimmer guard to the mounting point on the lower shaft using the 2 allen
screws provided.
3.7 Align the hole on the black outer collar with the hole on the main drive shaft
(highlighted) by turning the shaft until they line up.6
3.8 Insert the allen key through both holes, locking the drive shaft in place.
3.9 Undo the central nut and remove.
3.10 Remove the large domed washer (store in the tool kit bag).
3.11 Remove the small domed washer (store in the tool kit bag).
