- Page 1 3G/HD/SD-SDI Quad-view Video Processor User Manual...
-
Page 2: Table Of Contents
However, like all electronic equipments, the MX-3004 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
INTRODUCTION The MX-3004 3G/HD/SD-SDI Quad-view Video Processor is an advanced video processor for multimedia presentations. It is an ideal solution for some applications such as surveillance, where up to four SDI video signals must be displayed on a single display. It supports up to 4 SDI video inputs, of which four can be outputted simultaneously with the desired display layout through software control. -
Page 4: Specifications
SPECIFICATIONS Model Name MX-1004S MX-3004 Technical Role of usage Multiplexer / video processor Dual output support Yes [DVI & VGA] Yes [DVI & SDI] Background video input Composite [13.5MHz] DVI/HDMI[165MHz] Video bandwidth SDI [2.97Gpbs & 2.97/1.001Gbps] SDI 3G/HD/SD Video Input support... -
Page 5: Panel Descriptions
The MX-3004 has 4 SDI and user can display four of them simultaneously on the same screen. Figure 2 shows the rear panel connectors of a MX-3004 and Table 1 illustrates how you can connect video devices and display to the MX-3004. -
Page 6: Application Diagra
APPLICATION DIAGRA... -
Page 7: Hardware Installation
3. Connect a device equipped with SDI output including SD/HD/3G to the BNC input connector of MX-3004. 4. Connect a device equipped with composite video output to the BNC input connector of the MX-3004. 5. Connect your computer with the MX-3004 by a 9-pin RS-232 cable and then install the software. -
Page 8: Operation Software
OPERATION SOFTWARE System Requirement and Precautions 1. The device provides a software control program, Quartet, which runs under Microsoft Windows 98, 2000, XP, Vista, 7 through the interface of RS-232 serial control. 2. Before you click the icon of the software, make sure you have secured the connection between your computer COM port and the device and switched on the device with green LED light. - Page 9 TCP/IP Mode: Enter the device IP address and click the “Connect” Button. (How to set the IP address, please refer the part “TCPConfig” of “Tool Bar List”). After you select the connecting way to connect the device, it will be pop-up the window as below.
- Page 10 Instruction of Software Connection (connect with RS232) 1. PAP Panel: Display and adjust the window size and position. 2. Tool Bar List: : Get all information of the device and update this software state. Port setting: Pop-up the “Connect Select” dialog, user can select the connecting way.
- Page 11 Click this button, it will be pop-up the “Border Setting” management interface. Window drop-down list: Setting for window 1~4. Window Setting Border Color: Change the border color of window which you want. Border: Display the border or not. ...
- Page 12 User can adjust the window size and position, and basing on the user setting, they can save the different PAP mode in custom layout. (6) Crop Function: Pop-up the “Crop Video” dialog Picture Box: It is preview the range and effect of video crop with the adjustment. Window Channel: Choose the window to crop the video.
- Page 13 Horizontal Array Total = 3 Horizontal Array Start = 1 Horizontal Array End = 2 Vertical Array Total = 3 Vertical Array Start = 1 Vertical Array End = 2 Percent Tab:...
- Page 14 Pixel Tab: “Pixel” and “Percent” crop are almost same. It is different from modify value. : Version, click this button to show version information. 3. Output Resolution: Set the output resolution. When set the different resolution, the parameters of PAP and custom layout (position and size) will change.
- Page 15 4. Control Bar: For PAP Panel Setting. (1) Control Percent: 10~100% to set the PAP Panel display/control size. : Pop-Up the “PAP Layout Display” Dialog : Fix the size ratio when the window is resizing. 5. PAP Mode Control / Input Selection (1) Major Window: The major window for set the visible, position, size, polarity and default layout.
- Page 16 (2) PAP Mode: Set to last PAP layout. Default Layout: Set the default position and size with icon picture. The “major window” will be the largest size in the icon. ……… Custom Layout: Set the custom layout by customize saving with “Tool Bar List”...
- Page 17 Tool It is especially different between connect with RS232 and TCP/IP. Using TCP/IP connecting way, the function is limit to set up the flash setting, image update and firmware update. But the other function user can follow the instruction manual of the RS232 : Device flash Setting, it will pop-up the “Variable Flash Control”...
- Page 18 Image updating, it shall be pop-up the “Image Update” dialog. User can set up the image information for this device. Splash Screen: change the startup screen for the software. Font Data: To set up the display font. Background Image: User can install the picture into the device.
-
Page 19: Trouble Shooting
TROUBLE SHOOTING Problem Recommendations Check if you correctly and firmly plug AC power core into MX-3004 If you are recovering from power outage, accidentally unplug the power No power core or other power surge conditions, leave the device off for a while and then power it on again. -
Page 20: Limited Warranty
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the MX-3004 features and specifications is subject to change without further notice.
