2. Equipment Set-up and Installation
2.1
Unpacking the Ultramark Microplate Reader
Before opening the box, check for any outer damage. Document any damages, if present.
Place the box upright with the TOP label facing up and open the box. Remove the instrument from
the box in this position only.
Warning! Grasp the instrument firmly under the right and left sides before attempting to lift or carry
it.
Check the instrument for damaged or broken parts. Document any damages in detail.
Each Ultramark instrument includes the following accessories. Verify that they are present:
•
1 power cord.
•
1 plastic container with filter holder and 10 filters: 260 nm, 280 nm, 340 nm, 405 nm, 415 nm,
490 nm, 550 nm, 630 nm, 655 nm, and 750 nm.
•
1 user manual.
Verify that the serial number on the back of the instrument is the same as that on the outside of the
box.
Remove the side cover on the right side of the unit. Inside there are two docking brackets that need to
be removed by unscrewing 3 screws as shown on the unpacking sheet attached to the unit. After
removing the two docking brackets, install the Filter Magazine as described in the unpacking
instructions.
2.2
SCSI II Cable Connection
The SCSI II port is located on the back of the instrument. There are two connectors, which allows the
user to connect more than one SCSI instrument in a chain. If the Ultramark is the last instrument in
the chain, make sure that the termination switch (next to the SCSI connectors) is in the "ON" position.
If the Ultramark is an intermediate unit in the chain, make sure that the termination switch is in the
"OFF" position. If the Ultramark is the only unit connected to the SCSI cable, make sure that the
switch is in the "ON" position.
There is a small dial next to the SCSI connectors on the back of the unit. This dial selects the SCSI ID
number for the unit at boot-up. Be sure to select an ID number that is not being used by any other
SCSI device in the chain.
2.3
Power Connection
Before switching the power on for the first time, allow the Ultramark to warm to room temperature
for 6 hours after unpacking to prevent any condensation problems.
Plug the included power cord into the main power connector port. Make sure that the instrument is
connected to a grounded conductor of the main power outlet.
3
