8. Error Codes

The following error codes appear in the message window of the Ultramark.
Error Message Probable Cause
Memory(SRAM) An empty battery.
ROM replaced.
SRAM chip trouble.
Memory(DRAM) DRAM chip trouble.
Plate Carrier Dirty guide shaft, or something
blocking the guide shaft.
Motor drive damaged.
Photo sensor damaged.
X Axis Dirty guide rail , or something
blocking the rail.
Motor drive damaged.
Photo sensor damaged.
Y Axis
Dirty guide rail , or something
blocking the rail.
Motor drive damaged.
Photo sensor damaged.
Filter Miss Incomplete installation of filters
in the magazine.
Photo sensor damaged.
Filter ph-s Photo sensor damaged.
Incubator Incubator electronics
damaged.
Recommended Solution
Contact Bio-Rad.
Not a problem.
Contact Bio-Rad.
Contact Bio-Rad.
Confirm that there is nothing blocking
the guide shaft, then clean the shaft
and put some grease on it.
Contact Bio-Rad.
Contact Bio-Rad.
Confirm that there is nothing blocking
the guide rail, then clean the rail and
put grease on it.
Contact Bio-Rad.
Contact Bio-Rad.
Confirm that there is nothing blocking
the guide rail, then clean the rail and
put grease on it.
Contact Bio-Rad.
Contact Bio-Rad.
Install filters correctly into the
magazine.
Contact Bio-Rad.
Contact Bio-Rad.
Contact Bio-Rad.
15
