2.1.2. Description of the back panel and connections.

E A

2.1.2.1. Ethernet Ports (LAN 1 and LAN 2).

NETBOX 32 includes two Ethernet ports: LAN 1 must always be wired, while LAN 2 is only used
when the system is wired in "Daisy Chain" mode or a redundant system is set up. IMPORTANT
NOTE: When there is a redundant network, primary and secondary interfaces must be
connected to separated networks.
Physically, both are RJ45 10/100/1000, connectors, with the pinout described below:
White and Green
White and Orange

2.1.2.2. Analog Inputs and Outputs.

The physical connectors used are DB15-female. INPUTS (IN) connectors are placed in the
bottom row while OUTPUTS (OUT) are located in the upper row, with the following pinout:
Pinout of DB15 ANALOG IN 1 - 4 connector
- Pin 1: ANALOG 1 IN +
- Pin 2: GND
- Pin 3: ANALOG 2 IN +
- Pin 4: GND
- Pin 5: ANALOG 3 IN +
- Pin 6: GND
- Pin 7: ANALOG 4 IN +
- Pin 8: GND
D C
Pin 4:
Blue
Pin 3:
Pin 2:
Orange
Pin 1:
RJ45 connector pinout
B
- Pin 9: ANALOG 1 IN -
- Pin 10: GND
- Pin 11: ANALOG 2 IN -
- Pin 12: GND
- Pin 13: ANALOG 3 IN -
- Pin 14: GND
- Pin 15: ANALOG 4 IN -
AEQ NETBOX 32 AD / NETBOX 8 AD / NETBOX DSP
Audio over IP multichannel interfaces
A
Pin 5:
White and Blue
Pin 6:
Green
Pin 7:
White and Brown
Pin 8:
Brown
B
