- Page 1 Operating Instructions Translation of original operating instructions Vacuum Hand Laying Device SPEEDY VS-140/200; VS-140/200-XL; VS-140/200-110; VS-140/200-XL-110 5270.0011/5270.0012/5270.0013/5270.0014...
-
Page 2: Table Of Contents
Contents 2 / 25 Contents EC-Declaration of Conformity ..........................4 General ..................................5 Authorized use ..............................5 Safety ..................................8 Instructions for the Owner ..........................8 Instructions for the Installation, Maintenance and Operating Personnel ........... 8 Hazard Alert Symbols ............................. 8 Installation Site Requirements ........................ - Page 3 Maintenance ................................. 23 General ................................23 Maintenance Plan ............................23 Suction Pads / Seals ............................23 Leak Test ............................... 24 Safety procedures ............................24 Hints to the type plate ..........................25 Hints to the renting/leasing of PROBST devices ..................25 5270.0011/5270.0012/5270.0013/5270.0014...
-
Page 4: Ec-Declaration Of Conformity
Safety of machinery, electrical equipment of industrial machines. Part 1: General requirements. 2014/35/EU (Low voltage standard) 2014/30/EU (Electromagnetic compatibility) Authorized person for EC-documentation: Name: J. Holderied Address: Probst GmbH; Gottlieb-Daimler-Straße 6; 71729 Erdmannhausen, Germany Signature, information to the subscriber: Erdmannhausen, 09.10.2017................(M. Probst, Managing director) 5270.0011/5270.0012/5270.0013/5270.0014... -
Page 5: General
General 5 / 25 General Authorized use The “Vacuum Hand Laying Device S VS-140” is designed for lifting and moving stone and concrete slabs. PEEDY Operation requires two persons. The maximum lifting capacity must not be exceeded. The l” Vacuum Hand Laying Device” may be used only in vertical position. Transport of persons and animals with the load or the “Vacuum Hand Laying Device”... - Page 6 General 6 / 25 VS-SWV-SPS-50-30/25 (4271.0126) Quick-change suction plate The device is only designed for the use specified in this documentation. Every other use is not authorized and is forbidden! All relevant safety regulations, corresponding legal regulations, especially regulations of the declaration of conformity, and additional local health and safety regulations have to be observed.
- Page 7 Standard suction plates are not suitable for the transport of glass plates! Only suction plates of the manufacturer PROBST shall be used!!! Some suction plates which can be mounted to the device will reduce its carrying capacity. ·...
-
Page 8: Safety
Safety 8 / 25 Safety The lifting devices S VS series are manufactured according to current technical PEEDY Instructions for the standards and are safe. Nevertheless, they will present hazards Owner if they are not operated by qualified or at least trained staff, if they are used contrary to the approved applications. -
Page 9: Workplaces
Safety 9 / 25 The device is operated always by two persons. The workplace of the operators is in Workplaces front of the control handles. Stand so that you can constantly observe the vacuum gauge. As an operator of the lifting device, you must be trained before you start to use the Instructions for the device. -
Page 10: 3.14 Safety Marking
Safety 10 / 25 3.14 Safety Marking WARNING SIGN Symbol Meaning Order-No.: It is not allowed to be under hanging loads. Danger to life! 2904.0210 30 mm 2904.0209 50 mm 2904.0204 80 mm Do not lift any components off-centre. 2904.0383 102x52 mm WARNING SIGN Symbol... -
Page 11: Technical Data
Technical Data 11 / 25 Technical Data Dimensioned Drawing Description Description Operator handles Cover of the device Upper part of the device with blower motor Operating lever Suction plate Push switch Ventilating flap Vacuum gauge Lower part of the device 5270.0011/5270.0012/5270.0013/5270.0014... -
Page 12: Basic Device , Variants
Technical Data 12 / 25 Basic device , variants VS-140/200 (230 V) 5270.0011 VS-140/200-XL (230 V) 5270.0012 VS-140/200-110 (110 V) 5270.0013 VS-140/200-XL-110 (110 V) 5270.0014 Basic device, specifications Blower motor, power 1500 W 57200011 und 57200012 57200013 und 57200014 Blower motor, power / Frequenzy 230 V / 50 Hz 110 V / 50/60 Hz Temperature range... -
Page 13: Suitable Suction Plate Without Retrofit Kit Counterholder (Vs-Gh-Sps)
Technical Data 13 / 25 4.5.1 Suitable suction plate without retrofit kit counterholder (VS-GH-SPS) Type Lenght (mm) Width (mm) Carrying capacity / working Order-Nr. load limit (WLL) (kg) VS-SPS-50-30/25 4271.0134 VS-SPS-80-40/30 4271.0135 VS-SPS-100-50/30 4271.0136 VS-SPS-140-70/30 4271.0137 VS-SPS-200-85/34 850 4271.0133 4.5.2 Suitable suction plate with retrofit kit counterholders ( (VS-GH-SPS) Type Lenght (mm) -
Page 14: Description
Description 14 / 25 Description Components of the Lifting Device Parts with safety functions appear in bold type Description Description Operator handles Cover of the device Upper part of the device with blower motor Operating lever Suction pad Push switch Ventilating flap Vacuum gauge Lower part of the device... -
Page 15: Installation
Installation 15 / 25 Installation Preparing for use Move the operator handles (1) to the working position as follows: remove the spring clips (2) from the pins, pull out the pins, move the handles to the desired position (Pos. 1), insert the pins and secure them with the spring clips. Attention Transport position Connect electric power to the lifting device. -
Page 16: Switching Off At The End Of The Day
Installation 16 / 25 Before switching off the device with the push switch, allow it to run for at least 30 Switching off at the seconds with the venting valve open end of the day This loosens and removes any dirt which may have been deposited on the vacuum blower. -
Page 17: Mounting Of A Quick-Change Suction Plate (Optional)
Installation 17 / 25 Mounting of a quick-change suction plate (optional) The assembly of a quick-change suction plate is the same as the assembly of a normal suction plate: If a suction plate has already been installed on the unit, dismount it before. -
Page 18: Mounting Of The Suction Plate With Counterholder
Installation 18 / 25 Press the closing brackets (2) downwards - the clamping bracket is released from the counterholder. Repeat steps 1 and 2 on the other side of the device. The suction plate is now detached. Remove the suction plate. Mounting of the suction plate with counterholder Place the device on the suction plate in the center. -
Page 19: Operating
Operating 19 / 25 Operating The ground or floor in the working area should by clean and dry or rough enough Safety Instructions to ensure that the operating personnel cannot slip. The device is intended only for manual transport of paving stones or slabs. Never suspend it from a crane or mechanical shovel, etc. -
Page 20: Lifting, Transporting And Lowering Loads
Operating 20 / 25 The following operating steps must be checked by a qualified mechanic prior to use of Lifting, Transporting the device by the operating personnel. Correct any faults before the device is used. and Lowering Loads Switch the blower on. 7.2.1 Lifting Loads Position the lifting device directly above the load. -
Page 21: Lifting Eye With Safety Chain
Operating 21 / 25 When using the device SPEEDY VS“ at a lifting equipment (e.g. excavator) the Lifting eye with safety „Lifting eye with safety chain – VS-XL-EH“ should be installed. chain Lift the device with the sucked load just a little (10-20 cm), then remove the safety chain (1) from the chain case (2) and throw it under the lifted load. -
Page 22: Troubleshooting
Troubleshooting 22 / 25 The device may be installed and maintained only by qualified personnel such as Troubleshooting mechanics and electricians. After any repair or maintenance work, check the safety devices as described in the section “Safety”. Fault Cause Remedy Vacuum generation does not work no current supply check the current supply... -
Page 23: Maintenance
Maintenance 23 / 25 Maintenance The device may be installed and maintained only by qualified personnel such as General mechanics and electricians. Always disconnect the electric power before starting any maintenance work. The fans must not be opened during the guarantee period as this will entail loss of guarantee cover. -
Page 24: Leak Test
Maintenance 24 / 25 Check the device for leaks at least every three months. Leak Test Apply the suction pad to a flat air-tight surface. Switch the vacuum blower on and wait until a vacuum of at least -200 mbar is reached. -
Page 25: Hints To The Type Plate
Example: Hints to the renting/leasing of PROBST devices With every renting/leasing of PROBST devices the original operating instructions must be included unconditionally (in deviation of the users country's language, the respective translations of the original operating instructions must be delivered additionally)!
