- Page 1 SPEEDY VS-140 Vacuum Hand Laying Device VS-140-110 SPEEDY VS-140 Vacuum Hand Laying Device VS-140-110 Order-No: Serial-No.: 5270.0008 Translation of original operating instructions...
-
Page 2: Table Of Contents
Contents 06/08/14 VS-140-110 2 / 24 Contents Contents ..........................2 EC-Declaration of conformity....................4 Safety ............................ 6 Instructions for the Owner ....................6 Instructions for the Installation, Maintenance and Operating Personnel ....... 6 Hazard Alert Symbols ...................... 6 Installation Site Requirements ..................6 Intended Use ........................ - Page 3 Maintenance ........................19 General ..........................19 Maintenance Plan ......................19 Suction Pads / Seals......................20 Leak Test ........................20 Safety procedures ......................21 Hints to the identification plate ..................22 Hints to the renting/leasing of PROBST devices ............22 Spare Parts ......................... 23...
-
Page 4: Ec-Declaration Of Conformity
EC-Declaration of conformity 06/08/14 VS-140-110 4 / 24 EC-Declaration of conformity DESCRIPTION: SPEEDY VS-140 Vacuum Hand Laying Device VS-140-110 Manufacturer: Probst GreiftechnikVerlegesysteme GmbH Gottlieb-Daimler-Strasse 6 D-71729 Erdmannhausen info@probst.eu www.probst.eu Complies with the following provisions applying to it EC-machinery directive 2006/42/EG... - Page 5 Electromagnetic compatibility – Requirements for household appliances, electric tools, and similar apparatus. Part 2: Immunity. Authorized person for EC-dokumentation: Name: J. Holderied Address: Probst GreiftechnikVerlegesysteme GmbH; Gottlieb-Daimler-Str. 6; D-71729 Erdmannhausen Signature, informations to the subscriber: Erdmannhausen, 06.08.2014................(M. Probst, Managing director)
-
Page 6: Safety
Safety 06/08/14 VS-140-110 6 / 24 Safety The lifting devices S VS-S series are manufactured according to current technical PEEDY Instructions for the standards and are safe. Nevertheless, they will present hazards Owner ● if they are not operated by qualified or at least trained staff, ●... -
Page 7: Intended Use
Safety 06/08/14 VS-140-110 7 / 24 Lifting devices of the S VS-S are designed for lifting and moving stone and PEEDY Intended Use concrete slabs. Operation requires two persons. The maximum lifting capacity must not be exceeded. The lifting device may be used only in vertical position. Transport of persons and animals with the load or the lifting device itself is forbidden! Prohibition Unauthorised modification of the lifting device is forbidden for safety reasons! -
Page 8: Checking The Safety Devices
Safety 06/08/14 VS-140-110 8 / 24 The lifting device is equipped with following safety device: 3.12 Checking the Safety Devices vacuum gauge with red danger zone Check this device at the beginning of each shift (when operating in shifts) or once a week (when operating continually). -
Page 9: 3.13 Safety Marking
Safety 06/08/14 VS-140-110 9 / 24 3.13 Safety Marking WARNING SIGN Symbol Meaning Order-No.: It is not allowed to be under hanging loads. Danger to life! 2904.0101 Do not lift any components off-centre. 2904.0058 WARNING SIGN Symbol Meaning Order-No.: Size: Danger of squeezing the hands. -
Page 10: Technical Data
Technical Data 06/08/14 VS-140-110 10 / 24 Technical Data Dimensioned Drawing Description Description Operator handles Cover of the device Upper part of the device with blower motor Operating lever Suction plate Push switch Ventilating flap Vacuum gauge Lower part of the device... -
Page 11: Technical Data
Technical Data 06/08/14 VS-140-110 11 / 24 Technical Data Blower motor, Power 1500 W Blower motor, Voltage / Frequency 110 V 50 / 60 Hz Temperature range 0°C ... 40 °C Lifting load (at -200 mbar low pressure) depending on size of suction plate Dead weight* ~14 kg ( ~ 31 lbs) Dimension of the suction plate... -
Page 12: Description
If the suction pad is positioned off-centre, the workpiece may suddenly drop from the unit during lifting and lowering operations, since the load is then one-sided. Danger Only suction plates of the manufacturer PROBST shall be used! - Page 13 Description 06/08/14 VS-140-110 13 / 24 ● The device is only designed for the use specified in this documentation. ● Every other use is not authorized and is forbidden! ● All relevant safety regulations, corresponding legal regulations, especially regulations of the declaration of conformity, and additional local health and safety regulations have to be observed.
-
Page 14: Installation
Installation 06/08/14 VS-140-110 14 / 24 Installation Preparing for use Move the operator handles (1) to the working position as follows: remove the spring clips (2) from the pins, pull out the pins, move the handles to the desired position (Pos. 1), insert the pins and secure them with the spring clips. -
Page 15: Switching Off At The End Of The Day
Installation 06/08/14 VS-140-110 15 / 24 Before switching off the device with the push switch, allow it to run for at least 30 Switching off at the seconds with the venting valve open end of the day This loosens and removes any dirt which may have been deposited on the vacuum blower. -
Page 16: Operating
Operating 06/08/14 VS-140-110 16 / 24 Operating ● The ground or floor in the working area should by clean and dry or rough enough Safety Instructions to ensure that the operating personnel cannot slip. ● The device is intended only for manual transport of paving stones or slabs. Never suspend it from a crane or mechanical shovel, etc. -
Page 17: Lifting, Transporting And Lowering Loads
Operating 06/08/14 VS-140-110 17 / 24 The following operating steps must be checked by a qualified mechanic prior to use of Lifting, Transporting the device by the operating personnel. Correct any faults before the device is used. and Lowering Loads ●... -
Page 18: Troubleshooting
Troubleshooting 06/08/14 VS-140-110 18 / 24 Troubleshooting The device may be installed and maintained only by qualified personnel such as mechanics and electricians. After any repair or maintenance work, check the safety devices as described in the section “Safety”. Fault Cause Remedy Vacuum generation does not... -
Page 19: Maintenance
Maintenance 06/08/14 VS-140-110 19 / 24 Maintenance The device may be installed and maintained only by qualified personnel such as General mechanics and electricians. Always disconnect the electric power before starting any maintenance work. The fans must not be opened during the guarantee period as this will entail loss of guarantee cover. -
Page 20: Suction Pads / Seals
Maintenance 06/08/14 VS-140-110 20 / 24 Remove any foreign bodies and contamination such as adhesives, glue, sawdust, dust, Suction Pads / Seals etc. sticking to the seals at least once a week. Use glycerine to clean the seals. Immediately replace damaged seals (tears, holes, waves). Do not use petrol (gasoline). -
Page 21: Safety Procedures
Maintenance 06/08/14 VS-140-110 21 / 24 Safety procedures ● ● It is the contractors responsibility to ensure that the We recommend, that after checking the device is checked by an expert in periods of max. 1 device the badge „Safety checked“ is put year and all recognized errors are removed (... -
Page 22: Hints To The Identification Plate
Example: Hints to the renting/leasing of PROBST devices With every renting/leasing of PROBST devices the original operating instructions must be included unconditionally (in deviation of the users country's language, the respective translations of the original operating instructions must be delivered additionally)! -
Page 23: 10 Spare Parts
Spare Parts 06/08/14 VS-140-110 23 / 24 10 Spare Parts This equipment is guaranteed in accordance with our General Conditions of Business. This also applies to spare parts where these are original parts supplied by us. We will assume no liability for damage caused by the use of non-original spare parts and accessories. - Page 24 Spare Parts 06/08/14 VS-140-110 24 / 24 Pos. Bezeichnung / Description Art.-No. Betätigungshebel BH 90.800 / operating lever 4271.0036 Rundlitze mit Kugelpressnippel / round stranded wire with ball for bowden cable siehe/see Pos.7 Runddrahthülle / cover for bowden wire siehe/see Pos.7 Klett-/Velourband / belt ----- Lamellenstopfen / plug...
- Page 25 24100194 42710065 42710060 42710062 42710059 42710034 - 230V / 50Hz Bei Änderungen Rücksprache TB ! 42710035 - 110V / 60Hz Gewicht: 4,6 kg Schutzvermerk nach DIN 34 beachten! Nachdruck nur mit unserer Genehmigung! Benennung Datum Name Gebläseeinheit kompl. für Speedy VS-S Erst.
- Page 26 Proof of maintenance The claim under guarantee for this device only exists and is subject to the proper execution of the mandatory maintenance works. (In case of warranty request please always attach a copy of the proof of maintenance) Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Device type: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Article -No.:...
- Page 27 Proof of maintenance The claim under guarantee for this device only exists and is subject to the proper execution of the mandatory maintenance works. (In case of warranty request please always attach a copy of the proof of maintenance) Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Device type: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Article -No.:...
- Page 28 Proof of maintenance The claim under guarantee for this device only exists and is subject to the proper execution of the mandatory maintenance works. (In case of warranty request please always attach a copy of the proof of maintenance) Operator: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Device type: _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Article -No.:...
