WARNING!
NEVER use the XLINK Jumpers in place of a fuse
Cover any unused input with an Input Plug
XLINK systems should not exceed 500 AMP in total fusing
Stinger is a Power Brand of AAMP Global
15500 Lightwave Drive, Suite 202
Clearwater, Florida 33760
XFDB108 PATENT PENDING
Technical Support: 800-477-2267
StingerElectronics.com
support@stingerelectronics.com
© Copyright 2018
COMPONENTS
4 Gauge
Adapter
8 Gauge
Adapter
AFS/Mini ANL
Fuse Mount
Ground Jumper
XLINK X-Pansion Jumper
WARNING! NEVER use the XLINK jumpers in place of a fuse.
QUICK TIPS
XLINK Interlocking Base
To connect 2 or more XLINKS,
align locking channel and
press together.
XLINK Gauge Adapters
Convert to any combination of
0GA, 4GA or 8GA inputs and
outputs. Make sure the adapter opening
lines up with the wire set screw.
4mm
ANL
Fuse Mount
4 Gauge
Adapter
XLINK
*
Input
Plug
*
XLINK X-Pansion Jumper
Distribute power or ground across multiple
XLINK blocks by connecting the X-Pansion
jumper to input side of block.
Connecting this way; if a single circuit blows a
fuse, the XLINK block will continue providing to
power to the other circuits.
Wire Set Screw
Cover
8 Gauge
Adapter
