Section 1 Installation Checklist - Eaton ConnectUPS Web/SNMP Card Quick Start Instructions

Section 1 Installation Checklist
1. Verify that the following items are available:
o
o
o
o
2. If you are going to use Dynamic Host Configuration Protocol (DHCP), provide
your local network administrator with the card's MAC address. The MAC
address is located on either the shipping box label or the label on this card.
o
3. If you are not going to use DHCP to provide any of the settings listed below,
contact your local network administrator for the settings.
In the table below, check the DHCP check box or enter the values for manual
configuration.You will reference this data later in the procedure.
Item
IPv4
DNS – Name Servers
DNS – Domain
* The network administrator normally sets up the DHCP server to provide a static IP address each time
the card makes a DHCP request.
4. If you need e-mail functionality, obtain the SMTP mail server's IP address or
host name. If using the SMTP host name, verify that you also have the
Name Server IP address (see Step 3).
o
Eaton ConnectUPS Web/SNMP Card Quick Start Instructions 164950185—Rev D 4
ConnectUPS Web/SNMP card package contents (card, cable, Quick Start
Instructions)
®
Phillips screwdriver
Available USB port on a computer running Microsoft
Web browser (Microsoft Internet Explorer
® ®
Mozilla Firefox , or Google Chrome™ are recommended)
MAC Address _____________________________________________
DHCP*
SMTP (mail server) IP Address
or Host Name _____________________________________________
o
Card IP Address:
Netmask:
Gateway:
o
Name Server #1:
Name Server #2:
Name Server #3:
o
Domain:
®
Windows
®
version 8.0 and higher,
Manual Configuration
________________________
________________________
________________________
________________________
________________________
________________________
________________________
®
