Korenix JetWave 2111 Series User Manual

Wireless lte gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

JetWave 2111/2411 Series
Wireless LTE Gateway
User Manual
V1.0 Mar.18, 2019

Advertisement

Table of Contents
loading

Related Manuals for Korenix JetWave 2111 Series

Summary of Contents for Korenix JetWave 2111 Series

  • Page 1 JetWave 2111/2411 Series Wireless LTE Gateway User Manual V1.0 Mar.18, 2019...
  • Page 2 JetWave 2111/2411 Series User Manual Copyright Copyright © 2014 all rights reserved. No part of this publication may be reproduced, adapted, stored in a retrieval system, translated into any language, or transmitted in any form or by any means without the written permission of the supplier.
  • Page 3 JetWave 2111/2411 Series User Manual Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 4: Jetwave 2111/2411 Series

    JetWave 2111/2411 Series User Manual FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To avoid the possibility of exceeding radio frequency exposure limits, you shall beep a distance of at least 100cm between you and the antenna of the installed equipment.

  • Page 5: Table Of Contents

    How to Login the Web-based Interface ..................22 Fail to login the Web GUI ........................ 23 How to login the CLI ........................24 Discovery Utility – Korenix View Utility ..................25 Chapter 4 Web GUI Configuration ........................26 Status ..............................27 System ..............................
  • Page 6 Main Entry ............................69 Chapter 5 Configuration – SNMP, CLI, View Utility .................... 71 SNMP ..............................72 Command Line Interface (CLI) ..................... 113 Korenix View Utility ........................120 Chapter 6 Troubleshooting ..........................123 General Question ........................... 124 Wireless/Cellular ..........................125 Appendix ............................

  • Page 7: Chapter 1 Introduction

    JetWave 2111/2411 Series User Manual Chapter 1 Introduction...

  • Page 8: Introduction

    Korenix JetWave 2111/2411 LTE IP Gateway. The 2 product series equips with the same LTE technology, the same hardware/software platform and the same installation consideration for indoor or outdoor field box. For detail product specification, please download the latest datasheet from Korenix web site.

  • Page 9: Jetwave 2111/2411 Series Appearance

    JetWave 2111/2411 Series User Manual 1.2 JetWave 2111/2411 Series Appearance Figure - JetWave 2111 Appearance Figure - JetWave 2411 Appearance 2411...

  • Page 10: Jetwave 2111/2411 Major Features

    1 Fast Ethernet Port VPN/Firewall/DMZ and Secure VPN Connectivity • LAN to 4G/LTE Routing • Remote management by Web GUI, SNMP, Auto IP Report, Korenix View, Mobile Manager • • 24V(9~30V) DC power input • Wide Temperature, Heavy Industrial Grade design Support GPS (Optional) •...

  • Page 11: Product Package

    Quick Installation Guide Note: Please download the Utility, User Manual from Korenix Web Site. Note 1: Check the Korenix web site order information for new accessories, new version user manual, MIB file, firmware and Utility. Note 2: Different model needs different number of the accessories. If you are not familiar with the...

  • Page 12: Chapter 2 Hardware Installation

    JetWave 2111/2411 Series User Manual Chapter 2 Hardware Installation...

  • Page 13: Professional Installation Required

    JetWave 2111/2411 Series User Manual Chapter 2 Hardware Installation This chapter describes safety precautions and product information before installing JetWave 2111/2411 Series. 2.1 Professional Installation Required Please seek assistance from a professional installer for field installation or professional IT Engineer for indoor installation. The JetWave 2111/2411 series is distributed through distributors and system installers with professional technicians and will not be sold directly through retail stores.

  • Page 14: Power Installation

    JetWave 2111/2411 Series User Manual 2.2 Power Installation 2.2.1 DC Input There is one 6-pin terminal block within the package for screwing the DC wires. It is a good practice to turn off the system power, and to unplug power terminal block before making wire connections.

  • Page 15: I/O Configuration

    JetWave 2111/2411 Series User Manual 2.3 I/O Configuration 2.3.1 Wiring your Ethernet Port There are 1 Fast Ethernet port. The 1 port is standard RJ-45 form factor. They can support 10Base-TX, 100Base-TX. The 10/100Base-TX also support both full or half duplex mode. All the Ethernet ports will auto-detect the signal from connected devices to negotiate the link speed and duplex mode.
  • Page 16 JetWave 2111/2411 Series User Manual 2.3.3 Serial Port There is one RJ45 type serial port for serial communication on JetWave 2111/2411(S1). The serial port is designed for Serial over Cellular communication. The port supports RS232/422/485 3-in-1, and up to 460.8kbps baud rate. The software supports TCP/UDP connection. Page 13...
  • Page 17 JetWave 2111/2411 Series User Manual 2.3.4 SIM Socket The JetWave 2111/2411 provides one external SIM (Subscriber Identity Module) socket to store the LTE SIM card. Loosen the screw and then you can plug in the SIM card. SIM connecter The supported SIM card is Nano-SIM. Note: While you prepare to plug in the SIM card, please remember to power off the system first.
  • Page 18 JetWave 2111/2411 Series User Manual 2.3.5 Digital Input The system provides 1 digital input in the bottom side of the device. It allows users to connect the termination units’ digital output and manage/monitor the status of the connected unit. The Digital Input pin can be pulled high or low; thus the connected equipment can actively drive these pins high or low.
  • Page 19 JetWave 2111/2411 Series User Manual 2.3.7 Ground To ensure the system will not be damaged by noise or any electrical shock, we suggest you to make exact connection with the Earth Ground. There is one earth ground screw on the bottom side of the device.

  • Page 20: Led Indicator

    JetWave 2111/2411 Series User Manual 2.4 LED Indicator The following table indicates the LED of your device. Indication Indication Power 1 Status Digital Output Status Green ON = System ON Red ON = The Relay is ON. It may indicate the alarm of specific events. Ethernet Port 1 Status.

  • Page 21: Using The External Antenna

    JetWave 2111/2411 Series User Manual Using the External Antenna Consult your system integrator or our technical support engineer to choose the suitable external antenna with SMA-type or N-Type connector for your application. Different antenna supports different bands, polarization and different range of coverage. Antenna Socket of the Gateway: LTE2: SMA connector LTE antenna GPS: SMA connector GPS antenna (not included in the package please purchase if needed)

  • Page 22: Chapter 3 Prepare For Management

    JetWave 2111/2411 Series User Manual Chapter 3 Prepare for Management Page 19...

  • Page 23: Basic Factory Default Settings

    The chapter also tells you how to login the Web-based interface, Diagnostic Console. If you forget IP address you changed, you can use Korenix View Utility (refer to next chapter) to discover the devices’ IP address and then access it.
  • Page 24 JetWave 2111/2411 Series User Manual Get Community Public SNMP Set Community Private Trap Destination 0.0.0.0 Trap Community Public Device Search, IP Assign, Korenix View Utility Basic Tool, Wireless Panel Baud Rate 115,200 Diagnostic CLI Parameter N, 8, 1 Page 21...

  • Page 25: System Requirements

    JetWave 2111/2411 Series User Manual Warning: It is Important to change all the default settings of the Gateway, includes the User Name, Password, Default IP Address, Default SSID, SNMP Community Name and configure Wireless Security to secure your network. 3.2 System Requirements Before configuration, please make sure your system meets the following requirements: A computer coupled with 10/100Base-T(X) adapter;...

  • Page 26: Fail To Login The Web Gui

    JetWave 2111/2411 Series User Manual Enter the name of Account (Default: admin) and password (Default: admin) respectively and click “Login” to login the main page of the device. As you can see, this management interface provides main options in the above, which are Status, System, Management, Tools, Save, Reboot and Logout. Figure - Main Page Note: The username and password are case-sensitive!

  • Page 27: How To Login The Cli

    JetWave 2111/2411 Series User Manual 3.5 How to login the CLI Telnet/SSH: You can connect to the device by Telnet and the command lines. Below are the steps to open Telnet connection to the switch. 1. Go to Start -> Run -> cmd. And then press Enter 2.

  • Page 28: Discovery Utility - Korenix View Utility

    Please download the latest Korenix View Utility from Korenix Web Support page. The PC with Korenix View Utility can discover the Gateway cross the IP subnet. But, if you want to do further configuration, the PC must be located in the same subnet with your Gateway. Change the IP address of your PC or change the IP address of the Gateway.

  • Page 29: Chapter 4 Web Gui Configuration

    JetWave 2111/2411 Series User Manual Chapter 4 Web GUI Configuration Page 26...

  • Page 30: Status

    JetWave 2111/2411 Series User Manual Chapter 4 Web GUI Configuration This chapter describes the Web GUI for Software Configuration. 4.1 Status The Status feature set includes Information, Association List, Network Flow, Bridge Table, ARP Table and DHCP Client List. The information allows you to see the information of the device. 4.1.1 Information This page shows the current status and some basic setting of the device.
  • Page 31 JetWave 2111/2411 Series User Manual 4.1.2 Network Flow (Statistics): This page shows the packet counters for transmission and reception regarding to Cellular and Ethernet. Poll Interval: The poll interval time setting, range from 0~65534 seconds. If you want to change the poll interval time, press “Stop”...
  • Page 32 JetWave 2111/2411 Series User Manual 4.1.4 ARP Table This table shows the ARP table. IP Address: The IP Address leant from the interface. MAC Address: The MAC Address leant from the interface. Interface: The interface which learnt the ARP packet (IP and MAC Address). Refresh: Refresh the table.

  • Page 33: System

    JetWave 2111/2411 Series User Manual System For users who use the JetWave 2111/2411 series for the first time, it is recommended that you begin configuration from the “System” feature set pages shown below: In System pages, there are some configuration pages for the system settings. These setups are introduced in below pages.
  • Page 34 JetWave 2111/2411 Series User Manual 4.2.2 IP Settings interfaces. Here you may change Use this page to configure the IP related parameters for LAN the setting for IP address, subnet mask, Default Gateway, DNS, Static IP or DHCP…etc. LAN Settings: IP Address: The IP Address field allows you to set the device’s WAN IP address manually.
  • Page 35 JetWave 2111/2411 Series User Manual DHCP Server: Enabled / Disabled DHCP Server Setting: In Router mode, you can enable DHCP Server to assign IP address to DHCP clients. And you should define the address pool by configuring the Start IP and End IP. DHCP server will allocate IP address dynamically from the pool.
  • Page 36 JetWave 2111/2411 Series User Manual 4.2.3 Time Settings Use this page to configure the Time Settings. You can configure current time, time zone and configure NTP protocol to synchronize system time with a public time server over the internet. Current Time: You can manually type the current time or get the time from you PC. Click “Get PC time”, the current time will be updated according to your PC’s time.
  • Page 37 JetWave 2111/2411 Series User Manual 4.2.4 Relay Settings You can bind the selected events to Relay Output. While the event is activated, the Relay output is changed to “Open” status, the DO LED will turn on to alarm the administrators/technician. Link Failure: You can bind the Ethernet port failure event with Relay output.
  • Page 38 JetWave 2111/2411 Series User Manual 4.2.5 Serial Settings Use this page to configure the Serial Settings. The JetWave 2111/2114 series is equipped with one RS-232/422/485 3-in-1 Serial port. It supports TCP Server/Client and UDP for remote connection. This page allows you to configure the Serial interface’s parameters. Basic Settings: This page allows you configure basic settings of the Serial port.
  • Page 39 JetWave 2111/2411 Series User Manual the dropdown list. Tx Interval: Configure the Tx Interval time, the system will queue the transmit data before time interval expired. The time unit is millisecond. Service mode: You can select TCP Server, TCP Client, and UDP listening. Serial to Ethernet/ Ethernet to Serial Delimiter: Configure the Delimiter and Flush time (a timeout that the delimiter not matched) setting for Serial to Ethernet or Ethernet to Serial transmission.
  • Page 40 JetWave 2111/2411 Series User Manual “Dest IP Filtering”: Destination IP addresses Filtering from the LAN to Internet through the gateway. “Src Port Filtering”: Source Ports Filtering from the LAN to Internet through the gateway. “Dest Port Filtering”: Destination Ports Filtering from the LAN to Internet through the gateway. •...
  • Page 41 JetWave 2111/2411 Series User Manual (note for the entry) and then press “Apply” to activate the settings. After applied, the Web GUI will show “Change settings successfully”. Click “OK” and then you can see the new entry shown in the below table. •...
  • Page 42 JetWave 2111/2411 Series User Manual • Destination Port Filtering Entries in this table are used to restrict certain ports of data packets from your local network to Internet through the Gateway. Use of such filters can be helpful in securing or restricting your local network.
  • Page 43 JetWave 2111/2411 Series User Manual Press “Apply” to activate the settings. After applied, the Web GUI will show “Change settings successfully”. Click “OK” and then you can see the new entry shown in the above table. 4.2.9 NAT Settings NAT is the short of Network Address Translation, it is a methodology of modifying network address information in IP packet headers while they are in transit across a Gateway/Router for the purpose of remapping one IP address space into another.
  • Page 44 JetWave 2111/2411 Series User Manual Select “Enable Port Forwarding” and then type the parameters to create the port forwarding entries. Public Port Range: Configure the port range which will be public to WAN/Internet. You can configure one or a range of TCP/UDP port number. IP Address: Configure the IP Address of the LAN PC.
  • Page 45 JetWave 2111/2411 Series User Manual Select “Enable DMZ” and assign the IP address of the “DMZ Host IP Address”. This is the DMZ computer’s IP address. If you configure the DMZ function for your office network, please make sure this is agreed by the IT administrator. Press “Apply”...

  • Page 46: Cellular

    JetWave 2111/2411 Series User Manual Cellular The “Cellular” feature set pages allow users to see the LTE Status, configure the Basic LTE Setting, SIM Security and download the Debug message. 4.4.1 Status This page shows the current status and some basic settings of the device. After the LTE connected, some of the information will be updated per your ISP (Internet Service Provider).
  • Page 47 JetWave 2111/2411 Series User Manual IMEI: This item shows the International Mobile Equipment Identity (IMEI) of the LTE module. Signal Strength: The signal strength to the remote connected base station. If the signal strength shows low, please change the Gateway location or mounting the antenna in better location. Below are the signal strength definitions in our system: 0 dBm (Default value while no connection, or Read the Signal Strength error.)
  • Page 48 JetWave 2111/2411 Series User Manual 4.4.2 Basic Settings Normally, you can connect the LTE Gateway to the ISP cellular network without configuring LTE setting. However, in some countries, before the LTE gateway can access the ISP's cellular data network, you may need to enter the APN settings, User Name, Password, Authentication type… on the device.
  • Page 49 JetWave 2111/2411 Series User Manual Disable 4G/Cellular Interface: You can disable the LTE interface manually. APN: Every ISP has a specific APN (Access Point Name) assigned to its cellular network. The system can read this name from the SIM card. You can also find this setting by contacting your Page 46...
  • Page 50 JetWave 2111/2411 Series User Manual ISP to know this. Once you failed to connect your LTE cellular network, this is the first way you can check. Please check with your ISP to know the APN and correctly input the setting through the page.
  • Page 51 JetWave 2111/2411 Series User Manual After correctly enter the PID number, you can start the LTE connection or change the new PIN settings. Page 48...

  • Page 52: Gps

    JetWave 2111/2411 Series User Manual 4.5 GPS The “GPS” feature set pages allow users to enable or disable GPS feature. GPS feature is supported by JetWave 2111/2411. 4.5.1 Basic Setting Use this page to disable or enable GPS feature. Disable GPS: check to disable GPS and uncheck to enable GPS. Press apply button when setup is done to apply configurations.

  • Page 53: Vpn

    JetWave 2111/2411 Series User Manual seconds to minutes depends on environment conditions such as the position of antenna, shelter, weather condition, coating etc. Normally it should take about dozens of seconds. MAP: When positioning finished, the coordinates will be displayed. Press Map button and browser will be launched and link to google MAP using the coordinates reported.
  • Page 54 JetWave 2111/2411 Series User Manual yes: The VPN function already enabled. no: The VPN function not enabled yet. Connection Status: Connected: The VPN connection already built successfully. Disconnected: The VPN not connect. IPsec: Enabled: yes: The IPsec function already enabled. no: The IPsec function not enabled yet.
  • Page 55 Certificate Authority (CA) certificate and key which is used to sign each of the server and client certificates. Please refer to Korenix Jetbox 5630 user manual for example PKI key generation.
  • Page 56 JetWave 2111/2411 Series User Manual Encryption Mode: Select the encryption is Static or TLS. Static Key: Use a pre-shared static key. TLS: Use SSL/TLS + certificates for authentication and key exchange. Remote Server IP (1): Input the IP address of VPN server. Remote Server IP (2): Input the second IP address of VPN server if necessary.
  • Page 57 JetWave 2111/2411 Series User Manual Persist-tun: Select enable or disable the persist-tun, enable this function will keep tun(layer 3)/tap(layer 2) device linkup after Keepalive timeout, default value is Enable. Persist-key: Select enable or disable the persist-key, enable this function will keep the key first use if VPN restart after Keepalive timeout, default value is Enable.
  • Page 58 JetWave 2111/2411 Series User Manual The top-half page is a tool to generate public key. The content of current public key is displayed. New public key can be generated by pressing generate key button. An alert will be displayed to confirm the creation of new public key.

  • Page 59: Management

    JetWave 2111/2411 Series User Manual Left - IP of network interface : Left corresponds to right in IPsec point-to-point connection. The left and right IP settings should be the same in both IPSec endpoints. Enter interface IP address of left endpoint that can directly connected to right endpoint, for example, WAN port IP address in router mode or cellular IP address when using cellular network.
  • Page 60 JetWave 2111/2411 Series User Manual Use this page to configure the remote management privacy, select the event warming type and SNMP settings. Remote Management Privacy: You can select which kinds of remote service should be opened in your environment. The services include Telnet, SNMP, SMP Trap, SSH, Force HTTPS and E-mail Alert.
  • Page 61 JetWave 2111/2411 Series User Manual all requests. Set Community: Specify the community name (password) for the incoming SNMP_Set requests from the management station. By default, it is set to private. Trap Destination: Specify the IP address of the station to send the SNMP traps to. Trap Community: Specify the community name (password) sent with each trap to the manager.
  • Page 62 JetWave 2111/2411 Series User Manual 4.7.2 SMTP Configuration The Gateway supports E-mail Warning feature. The Gateway will send the occurred events to remote E-mail server. The receiver can then receive notification by E-mail. The E-mail warning is conformed to SMTP standard. This page allows you to enable E-mail Alert, assign the SMTP Server IP, Sender E-mail, and Receiver E-mail.
  • Page 63 4.7.4 Firmware Upgrade In this section, you can update the latest firmware for your Gateway. Korenix provides the latest firmware in Korenix Web site. The new firmware may include new features, bug fixes or other software changes. We’ll also provide the release notes for the update as well.
  • Page 64 JetWave 2111/2411 Series User Manual 4.7.5 Configuration File The Gateway provides Configuration File Backup (Save Setting to File), Restore (Load Setting from File) and Reset Setting to Default features. With Backup command, you can save current configuration file saved in the Gateway’s flash to admin PC.
  • Page 65 JetWave 2111/2411 Series User Manual 4.7.6 Certificate File Use this page to import/delete user certificate file. You can import user certificate file, select “Browse…” to select the certificate file and press “Import”. You can generate the file by 3 tool, web site or get from the IT administrator. Following is the security setting under “WPA with Radius”...

  • Page 66: Tools

    JetWave 2111/2411 Series User Manual 4.8 Tools The “Tools” feature set pages provides some additional useful tools. The System Log help you see the occurred event logs, Ping Watchdog, Data Rate Test, Antenna Alignment and Ping tool. 4.8.1 System Log Use this pages to set remote log server and show the system log.
  • Page 67 JetWave 2111/2411 Series User Manual 4.8.2 Site Survey While your Gateway is in Wireless Client mode, this page provides tool to scan the wireless network. You can monitor current existed wireless network, connect to the SSID with better signal strength…etc. Interface: Select the interface number.
  • Page 68 JetWave 2111/2411 Series User Manual 4.8.3 Ping Watchdog This page provides a tool configure the Ping Watchdog. If the failure count of the Ping reaches to a specified value, the watchdog will reboot the device. Select “Enable Ping Watchdog” to enable the function. IP Address to Ping: This is the target IP address of the Ping Watchdog.
  • Page 69 JetWave 2111/2411 Series User Manual 4.8.4 Data Rate Test This page allows you to do Data Rate test to check the connection performance. This is a reference data for field test. The system will generate packet from one end to the other end. Wireless Interface: Select the WLAN 1 or WLAN 2.
  • Page 70 JetWave 2111/2411 Series User Manual 4.8.5 Antenna Alignment The Antenna Alignment tool is a convenient tool to find the target Gateway while you install the AP for long distance connection. In long distance transmission, it is not easy to see the remote Gateway clearly, with this tool, you can adjust the direction of the antenna and find out the best direction according to the result.
  • Page 71 JetWave 2111/2411 Series User Manual 4.8.6 Ping This is a simple Ping tool for you to check the status of remote station. Type the target IP address in the “Destination: _” field then press “Ping”. The system will ping the remote station 4 times and list the ping result in the web GUI. Page 68...

  • Page 72: Main Entry

    JetWave 2111/2411 Series User Manual 4.9 Main Entry The main entry provides the system tools, for example Save the configuration, Logout and Reboot the system. 4.9.1 Save Use this page to save configuration to flash. Every time while you finished the configuring the device, please remember to save the configuration to flash.
  • Page 73 JetWave 2111/2411 Series User Manual Page 70...

  • Page 74: Chapter 5 Configuration - Snmp, Cli, View Utility

    JetWave 2111/2411 Series User Manual Chapter 5 Configuration – SNMP, CLI, View Utility Page 71...

  • Page 75: Snmp

    JetWave 2111/2411 Series User Manual Chapter 5 Configuration – SNMP, CLI, View Utility 5.1 SNMP 5.1.1 What is SNMP? Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices. SNMP is a member of the TCP/IP protocol suite.
  • Page 76 Before you want to manage the JetWave 2111/2411 series Gateway through SNMP, please go to download the MIB files from Korenix web site and compile all of them to the NMS. The Gateway supports function based MIB, the same function/parameters in all the models have the same object ID (OID).
  • Page 77 JetWave 2111/2411 Series User Manual 5.1.3 MIB Tree in NMS .The below figure shows the MIB tree after compiled in the NMS. Page 110...
  • Page 78 JetWave 2111/2411 Series User Manual Example: wlanSetting wlanSettingEntry: Page 111...
  • Page 79 JetWave 2111/2411 Series User Manual Example of Object in wlanSettingEntry Operatemode: (Operation Mode) The OID: 1.3.6.1.4.1.24062.2.12.1.1.1.1.1 Max Access: read-write (Read and Write) Value list: you can read the value or set a new value according to the value list. This is the same as web GUI and CLI.

  • Page 80: Command Line Interface (Cli)

    JetWave 2111/2411 Series User Manual 5.2 Command Line Interface (CLI) The Gateway provides the Command Line Interface (CLI), you can access it through the console or Telnet. The Command Line Interface (CLI) is the user interface to the Gateway’s embedded software system. You can view the system information, show the status, configure the switch and receive a response back from the system by keying in a command.
  • Page 81 JetWave 2111/2411 Series User Manual 5.2.1 SHOW Command Set: Type Show + “Tab↹ ” to see all the show command sets. The following command lines are available. Type Show wlan + “Tab↹” to see all the show wlan command lines. Page 114...
  • Page 82 JetWave 2111/2411 Series User Manual Type Show wlan + “Enter” to see all the wlan information. The console print all the information for reference. korenixffffff>show wlan wlan wirelessmode : AP wlan ssid : 3200 wlan ssidhided : Disabled wlan radio : Enabled wlan 802.11mode : 802.11G/N...
  • Page 83 JetWave 2111/2411 Series User Manual For example: Type show wlan ra + “Tab” to complete the commands, and then you can see the result. korenixffffff>show wlan ra (+Tab) rate radio korenixffffff>show wlan rad (+Tab) rate radio korenixffffff>show wlan radio (+ Enter) radio : Enabled (This is the result.)
  • Page 84 JetWave 2111/2411 Series User Manual Example: Set the remote configuration (Refer to the 4.5.1 – Remote Configuration) korenixffffff>set remote (+Tab) alter event warning forcehttps smtp email snmptrap telnet snmp Example: SNMP Enable/Disable: korenixffffff>set remote snmp Disabled Enabled korenixffffff>set remote snmp Disabled remote snmp : Disabled korenixffffff>set remote snmp Enabled...
  • Page 85 JetWave 2111/2411 Series User Manual 5.2.3 List Command Set: Type List + “Tab↹ ” to see all the command usage. This is similar to the Help command. Below command is to list the remote configuration command line and its description. korenixffffff>list remote show set del keyword...
  • Page 86 JetWave 2111/2411 Series User Manual show, set and del: Which privilege the command has? [X] means Yes. Keyword: The command you should enter in the CLI. Description: Short description of the usage of the command. 5.2.4 Delete Command Set: Type del + “Tab↹ ” to see all the delete command sets. The following command lines are available.

  • Page 87: Korenix View Utility

    JetWave 2111/2411 Series User Manual 5.3 Korenix View Utility The Korenix View Utility (rename from the JetView V1.5.7) provides you convenient tool to scan the network and configure the AP. Please connect your PC to port Eth 2 (LAN) and start below steps to scan and configure.
  • Page 88 You can restore to default configuration by “Load Factory Default”. A popup screen will ask you confirm again. Note: You can also find these commands in the upper menu of the Korenix View Utility. 5.3.3 Wireless Panel Page 121...
  • Page 89 JetWave 2111/2411 Series User Manual New version Korenix View Utility provides Wireless panel to configure some Basic Setting and Security setting for Wireless LAN Interfaces. You can use the tool to configure settings for single device or a group of devices. Select the target device/devices for further configuration.

  • Page 90: Chapter 6 Troubleshooting

    JetWave 2111/2411 Series User Manual Chapter 6 Troubleshooting Page 123...

  • Page 91: General Question

    Login the unit via other browsers such as Firefox, Google Chrome.  Use Korenix View Utility to scan the AP and check/modify the IP address.  If everything is correct, but, you still can’t access the web GUI, we suggest you connect the console cable to do further checking.

  • Page 92: Wireless/Cellular

    JetWave 2111/2411 Series User Manual 6.2 Wireless/Cellular 6.2.1 What if the wireless connection is not stable after associating with an AP under wireless client mode? • In addition, you can start “Site Survey” to check the signal strength. If it is weak or unstable (The smaller the number is, the weaker the signal strength is.), please join other available AP for better connection.
  • Page 93 JetWave 2111/2411 Series User Manual • Check whether the antenna supports LTE band or not? Normally, the outlook of the LTE antenna is the same. • Check with the ISP and ask them check LTE connection condition of your site. •...

  • Page 94: Appendix

    JetWave 2111/2411 Series User Manual 6.3 Appendix 6.3.1 ASCII WEP can be configured with a 64-bit or 128-bit Shared Key (hexadecimal number or ACSII). As defined, hexadecimal number is represented by 0-9, A-F or a-f; ACSII is represented by 0-9, A-F, a-f or punctuation.
  • Page 95 The figure in the right is the lookup table for your reference. While comparing Korenix product with other competitors, you can follow the way to convert Korenix RSSI to % of the maximum RF Tx Power of other products. Page 128...
  • Page 96 JetWave 2111/2411 Series User Manual RSSI Conversion in Cisco for reference: Cisco has the most granular dBm lookup table. RSSI_Max = 100, Range from -10~-113dBm Convert % to RSSI in the following table. The RSSI is on the left, and the corresponding dBm value (a negative number) is on the right.
  • Page 97 JetWave 2111/2411 Series User Manual 6.3.3 JetWave 2111/2411 Web GUI Pages The firmware V1.0 released by Mar. 18, 2019 starts to support JetWave 2111/2411 Series. This appendix shows the JetWave 2111/2411 login page, Information and Main GUI. The JetWave 3420 Login Page The JetWave 3420 Main Entries The 4G setting is changed to “Cellular”.
  • Page 98 JetWave 2111/2411 Series User Manual Page 132...

  • Page 99: Revision History

    JetWave 2111/2411 Series User Manual Revision History Version Description Date Editor release for JetWave2111/2411 1.0 V1.0 March, 2019 Andrew Chen Page 133...
