- Page 1 JetLink 1102/ JetLink 1302 User Manual Korenix JetLink 1102 Industrial Modbus RTU/TCP to EtherNet/IP Fieldbus Gateway, -10~60℃ Korenix JetLink 1302 Industrial Modbus RTU/TCP to PROFINET Fieldbus Gateway, -10~60℃ User Manual Ver. 01, Oct-2018 Firmware V1.0 www.korenix.com...
- Page 2 JetLink 1102/ JetLink 1302 User Manual Korenix JetLink 1102 Industrial Modbus RTU/TCP to EtherNet/IP Fieldbus Gateway, -10~60℃ Korenix JetLink 1302 Industrial Modbus RTU/TCP to PROFINET Fieldbus Gateway, -10~60℃ User’s Manual Copyright Notice Copyright 2018 Korenix Technology Co., Ltd. All rights reserved.
- Page 3 JetLink 1102/ JetLink 1302 User Manual Korenix warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for five years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Korenix, or which have been subject to misuse, abuse, accident or improper installation.
- Page 4 2. Contact your distributor, sales representative, or Korenix's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: – Product name and serial number –...
- Page 5 JetLink 1102/ JetLink 1302 User Manual Warnings, Cautions and Notes Warning! Warnings indicate conditions, which if not observed, can cause personal injury! Caution! Cautions are included to help you avoid damaging hardware or losing data. e.g. There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery.
- Page 6 JetLink 1102/ JetLink 1302 User Manual Safety Instructions Read these safety instructions carefully. Keep this User Manual for later reference. Disconnect this equipment from any DC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning.
- Page 7 JetLink 1102/ JetLink 1302 User Manual Safety Precaution - Static Electricity Static electricity can cause bodily harm or damage electronic devices. To avoid dam- age, keep static-sensitive devices in the static-protective packaging until the installa- tion period. The following guidelines are also recommended: ...
-
Page 8: Table Of Contents
JetLink 1102/ JetLink 1302 User Manual Index PRODUCT OVERVIEW..............10 SPECIFICATIONS ..................10 HARDWARE VIEWS ..................11 1.2.1 Front View .......................... 11 1.2.2 Rear View .......................... 13 1.2.3 Top View ..........................14 1.2.4 Bottom View ........................14 1.2.5 LED Indicators ........................15 1.2.5.1... - Page 9 JetLink 1102/ JetLink 1302 User Manual LOG IN ......................34 3.1.1 Changing Default Password ..................... 34 OVERVIEW ....................35 3.2.1 Device Information ......................35 3.2.2 Diagnose ........................... 37 3.2.3 Data View .......................... 38 NETWORK SETTING .................. 39 3.3.1 IP Setting ........................... 39 SERIAL SETTINGS ..................
-
Page 10: Product Overview
JetLink 1102/ JetLink 1302 User Manual 1 Product Overview SPECIFICATIONS... -
Page 11: Hardware Views
JetLink 1102/ JetLink 1302 User Manual HARDWARE VIEWS Front View 1.2.1 Figure 1.2 Front View (JETLINK1102) No. Item Description See “LED Indicators” on Page 15 for further details. System LED panel Default Press less than 5 seconds to restart device, press over 5 sec- onds to reset to factory default. - Page 12 JetLink 1102/ JetLink 1302 User Manual Figure 1.3 Front View (JETLINK1302) Item Description See “LED Indicators” on page 15 for further details. System LED panel Default Press less than 5 seconds to restart device, press over 5 sec- onds to reset to factory default.
-
Page 13: Rear View
JetLink 1102/ JetLink 1302 User Manual Rear View 1.2.2 Figure 1.4 Rear View... -
Page 14: Top View
JetLink 1102/ JetLink 1302 User Manual Top View 1.2.3 Figure 1.5 Top View No. Item Description Terminal block Connect cabling for power and alarm wiring Wall mounting holes Screw holes (x4) used in the installation of a wall mounting plate... -
Page 15: Led Indicators
JetLink 1102/ JetLink 1302 User Manual LED Indicators 1.2.5 JetLink 1102 Catalog LED Name LED Color Description Green Power 1 is ON Power 1 is off or power error condition exists Green Power 2 is ON Power 2 is off or power error condition exists... -
Page 16: Jetlink 1302
JetLink 1102/ JetLink 1302 User Manual 1.2.5.1 JetLink 1302 Catalog LED Name LED Color Description Green Power 1 is ON Power 1 is off or power error condition exists Green Power 2 is ON Power 2 is off or power error condition exists... -
Page 17: Dimensions
JetLink 1102/ JetLink 1302 User Manual DIMENSIONS Figure 1.7 Dimensions (JetLink1102/1302) -
Page 18: Fieldbus Gateway Installation
JetLink 1102/ JetLink 1302 User Manual 2 Fieldbus Gateway Installation INSTALLATION GUIDELINES The following guidelines are provided to optimize the device performance. Review the guidelines before installing the device. Make sure cabling is away from sources of electrical noise. Radios, power lines, and fluorescent lighting fixtures can interference with the device performance. -
Page 19: Installing The Fieldbus Gateway
JetLink 1102/ JetLink 1302 User Manual The fieldbus gateway is now ready for installation on its final location. INSTALLING THE FIELDBUS GATEWAY DIN Rail Mounting 2.3.1 The DIN rail mount option is the quickest installation option. Additionally, it optimizes the use of rail space. - Page 20 JetLink 1102/ JetLink 1302 User Manual See the following figure for an illustration of a completed DIN installation proce- dure. 3. Grasp the bottom of the fieldbus gateway and slightly rotate it upwards. If there is resistance, the fieldbus gateway is correctly installed. Otherwise, re-attempt...
-
Page 21: Removing The Din-Rail Mounting Kit
JetLink 1102/ JetLink 1302 User Manual 2.3.1.2 Removing the DIN-Rail Mounting Kit 1. Ensure that power is removed from the fieldbus gateway, and disconnect all cables and connectors from the front panel of the fieldbus gateway. 2. Push down on the top of the DIN rail clip release tab with your finger. As the clip releases, lift the bottom of the fieldbus gateway, as shown in the following illus- tration. -
Page 22: Wall-Mounting
JetLink 1102/ JetLink 1302 User Manual Wall-Mounting 2.3.2 The wall mounting option provides better shock and vibration resistance than the DIN rail vertical mount. Note! When installing, make sure to allow for enough space to properly install the cabling Before the device can be mounted on a wall, you will need to remove the DIN rail plate. - Page 23 JetLink 1102/ JetLink 1302 User Manual Once the wall mounting plates are secure on the device, you will need to attach the wall screws (x4). 6. Locate the installation site and place the fieldbus gateway against the wall, mak- ing sure it is the final installation location.
- Page 24 JetLink 1102/ JetLink 1302 User Manual...
-
Page 25: Connecting The Fieldbus Gateway To Ethernet Ports
JetLink 1102/ JetLink 1302 User Manual CONNECTING THE FIELDBUS GATEWAY TO ETHERNET PORTS RJ45 Ethernet Cable Wiring 2.4.1 For RJ45 connectors, data-quality, twisted pair cabling (rated CAT5 or better) is rec- ommended. The connector bodies on the RJ45 Ethernet ports are metallic and con- nected to the GND terminal. -
Page 26: Microsd Card Installation
JetLink 1102/ JetLink 1302 User Manual MICROSD CARD INSTALLATION The JetLink Seies provides user with an easy way to backup, restore, and deploy configuration settings. The fieldbus gateway provides a microSD card slot to support simple means to manage system configuration settings. -
Page 27: Utilizing A Microsd Card
JetLink 1102/ JetLink 1302 User Manual 5. Close the component cover. Utilizing a MicroSD Card 2.6.2 1. The device includes a microSD port to provide easy functionality to backup and deployment operations. The following information describes the supported uses when a microSD card (FAT32 or exFAT) is installed in the device. -
Page 28: Power Supply Installation
JetLink 1102/ JetLink 1302 User Manual 4. Check that the file system is not corrupted. 5. Check that the microSD card is not damage. If any of the events occur, the fieldbus gateway halts operation and the status LED begins flashing. -
Page 29: Considerations
JetLink 1102/ JetLink 1302 User Manual Considerations 2.7.2 Take into consideration the following guidelines before wiring the device: The Terminal Block (CN1) is suitable for 12-24 AWG (3.31 - 0.205 mm2). Torque value 7 lb-in. The cross sectional area of the earthing conductors shall be at least 3.31 mm2. -
Page 30: Wiring A Relay Contact
JetLink 1102/ JetLink 1302 User Manual Caution! Do not service any components unless qualified and authorized to do so. Caution! Do not block air ventilation holes. Electromagnetic Interference (EMI) affects the transmission performance of a device. By properly grounding the device to earth ground through a drain wire, you can setup the best possible noise immunity and emissions. -
Page 31: Wiring The Power Inputs
JetLink 1102/ JetLink 1302 User Manual The terminal receptor includes a total of six pins: two for PWR1, two for PWR2 and two for a fault circuit. Wiring the Power Inputs 2.7.5 Caution! Do not disconnect modules or cabling unless the power is first switched off. - Page 32 JetLink 1102/ JetLink 1302 User Manual 2. Remove the terminal block from the fieldbus gateway. 3. Insert a small flat-bladed screwdriver in the V1+/V1- wire-clamp screws, and loosen the screws. 4. Insert the negative/positive DC wires into the V+/V- terminals of PW1. If setting up power redundancy, connect PW2 in the same manner.
-
Page 33: Reset Button
JetLink 1102/ JetLink 1302 User Manual 8. Tighten the screws on the terminal block to secure it to the terminal block recep- tor. If there is no gap between the terminal block and the terminal receptor, the ter- minal block is seated correctly. -
Page 34: Managing Fieldbus Gateway
JetLink 1102/ JetLink 1302 User Manual 3 Managing Fieldbus Gateway LOG IN To access the login window, connect the device to the network, see “Connecting the Fieldbus Gateway to Ethernet Ports” on page 25. Once the fieldbus gateway is installed and connected, power on the fieldbus gateway see the following procedures to log into your fieldbus gateway. -
Page 35: Overview
JetLink 1102/ JetLink 1302 User Manual 1. Navigate to System Management > Change Password. 2. In the Password field, type in the new password. Re-type the same password in the Confirmation field. 3. Click Apply to change the current settings. - Page 36 JetLink 1102/ JetLink 1302 User Manual The following table describes the items in the previous figure. Item Description MAC Address Displays the MAC address of the device. Mode Displays the IP address setting mode of the device IP Address Displays the assigned IP address of the device.
-
Page 37: Diagnose
Displays the assigned gateway of the device. Diagnose 3.2.2 The following tables are only available for JetLink 1102. The ensuing table for EtherNet/IP Instance table settings are informational only: AA, O->T Instance (Exclusive Owner), Exclusive Owner Data Size, O->T Instance(Input Only), Input Only Data Size, T->O Instance and T->O Instance... -
Page 38: Data View
JeyLink1102, and Profinet slot data for JetLink1302. To access this page, click Overview > Data View. The following figure displays the menu as found in the JetLink1102. Figure 3.8 Overview > Data View (JetLink 1102) The following table describes the items in the previous figure. Item... -
Page 39: Network Setting
JetLink 1102/ JetLink 1302 User Manual The following figure displays the menu as found in the JetLink1302. Figure 3.9 Overview > Data View (JetLink1302) NETWORK SETTING IP Setting 3.3.1 The IP Setting menu allows you to select a static or DHCP network configuration. The Static displays the configurable settings for the static option. - Page 40 JetLink 1102/ JetLink 1302 User Manual The following table describes the items in the previous figure. Item Description Modbus/TCP and EtherNet/IP interface use the same IP address setting Mode Click the drop-down menu to select the IP address setting mode: Static address, or DHCP client.
- Page 41 JetLink 1102/ JetLink 1302 User Manual The following figure displays the menu as found in the JetLink1302 The following table describes the items in the previous figure. Item Description Modbus/TCP and EtherNet/IP interface use the same IP address setting Mode Click the drop-down menu to select the IP address setting mode: Static address, or DHCP client.
-
Page 42: Serial Settings
JetLink 1102/ JetLink 1302 User Manual SERIAL SETTINGS Port 3.4.1 To access this page, click Serial Settings > Port 1/Port 2. The following table describes the items in the previous figure. Item Description Type Click the drop-down menu to select a serial interface: RS232, RS422 or RS485. -
Page 43: Protocol Setting
JetLink 1102/ JetLink 1302 User Manual PROTOCOL SETTING EtherNet/IP Setting 3.5.1 On the EtherNet/IP network, the gateway transmits mapped data to scanner through I/O data. The first two I/O mapped bytes in either direction can be dedicated for status/control information, and another 64 bytes of data coming from the Modbus/ TCP network can feature the Modbus exception codes. -
Page 44: Profinet Setting
JetLink 1102/ JetLink 1302 User Manual PROFINET Setting 3.5.2 On the PROFINET network, the gateway transmits mapped data to PROFINET I/O Slot.There are two types of slot mappings as defined in the following figure.The PROFINET Setting page is only available for JETLINK1302. To access this page, click Protocol Setting >... -
Page 45: Modbus Setting
JetLink 1102/ JetLink 1302 User Manual Modbus Setting 3.5.3 To communicate with remote Modbus/TCP slave devices, specify the Modbus command for each slave device. Each slave device may need more than one command for communication, so it is necessary to add all the commands manually. - Page 46 JetLink 1102/ JetLink 1302 User Manual To add a new transaction: Figure 3.18 Protocol Setting > Modbus Setting > Add The following table describes the items in the previous figure.
- Page 47 JetLink 1102/ JetLink 1302 User Manual...
-
Page 48: Mapping Overview
JetLink 1102/ JetLink 1302 User Manual Mapping Overview 3.5.4 The Mapping Overview function allows the viewing of data between Modbus RTU/ TCP to PROFINET Slot, EtherNet/IP I/O. To access this page, click Protocol Setting > Mapping Overview. The following tables are only available for JetLink1102. -
Page 49: Backup Manager
JetLink 1102/ JetLink 1302 User Manual The following table describes the items in the previous figure. If you want to disable the password protection, change the password to the default option None (leave the password column blank). Be sure apply and reboot the system (System Management >... -
Page 50: Upgrade Manager
JetLink 1102/ JetLink 1302 User Manual The following table describes the items in the previous figure. Upgrade Manager 3.6.3 The Upgrade Manager page allows you to upgrade firmware. To access this page, click System Management > Upgrade Manager. Figure 3.22 System Management > Upgrade Manager The following table describes the items in the previous figure. -
Page 51: Reboot Device
JetLink 1102/ JetLink 1302 User Manual Reboot Device 3.6.5 To access this page, click System Management > Reboot Device. Click Reboot to reboot the fieldbus gateway. Any configuration changes you have made since the last time you issued a save will be lost. -
Page 52: Modbus Traffic Catcher
JetLink 1102/ JetLink 1302 User Manual Modbus Traffic Catcher 3.7.1 The Modbus Traffic Catcher page shows only data sent and received by Modbus. To access this page, click Tools > Modbus Traffic Catcher. Figure 3.26 Tools > Modbus Traffic Catcher...
