Altronix eBridge Plus Series Installation Manual page 3

Fig. 2
eBridge1PCR
eBridge1PCR
Input: 24VDC/1000mA, 24VAC/900mA (under maximum load).
Blue LED Coax link status (SLOC)
RJ45 LEDs Yellow - Speed, Green - Activity
Green LED Power and PoE
NVR Network
Video Server
I.T.E. 43KC
(Head End
Equipment)
100m
max.
Ethernet Switch
Fig. 3
100m max.
NVR Network
Video Server
(Head End
100m max.
Equipment)
100m max.
100m max.
Ethernet Switch
Maximum Length of Coax Type vs. Camera Power/PoE Class:
Camera
RG59/U -
Power/
23AWG
PoE Class
13W/0 261
4W/1 500
6.5W/2 500
13W/3 261
eBridge1PCRT
All manuals and user guides at all-guides.com
Single PoE Camera Connection:
EoC Receiver
provides PoE
Z1409
www.altronix.com
24VAC/VDC
Input
PoC (Power over Coax)
Up to 500m
Multiple PoE Cameras Connection:
eBridge1PCR
PoC (Power over Coax)
24VAC/
24VDC Up to 500m
eBridge1PCR
24VAC/
PoC (Power over Coax)
24VDC
Up to 500m
eBridge1PCR
24VAC/
PoC (Power over Coax)
24VDC
Up to 500m
eBridge1PCR
24VAC/
PoC (Power over Coax)
24VDC
Up to 500m
RG59/U -
22AWG
Max. Length (meters)
336
500
500
336
Fig. 2a
eBridge1PCT
eBridge1PCT
EoC Transceiver
provides PoE
Blue LED Coax link status
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power
Z1409
I.T.E. 43KC
www.altronix.com
PoE compliant
eBridge1PCT
100m max.
PoE compliant
eBridge1PCT
100m max.
PoE compliant
eBridge1PCT
100m max.
PoE compliant
eBridge1PCT
100m max.
Coax Type
RG59/U - RG59/U -
20AWG 18AWG
500 500
500 500
500 500
500 500
Mounting Hole
PoE Camera
PoE compliant
100m max.
Legend:
Coax
Structured Cable
PoE Camera
PoE Camera
PoE Camera
PoE Camera
Legend:
Coax
Structured Cable
RG6/U -
18AWG
500
500
500
500
- 3 -
