Vertiv Liebert iCOM CMS Installer/User Manual page 7

Figure 1.1 iCOM CMS web-based user interface
ITEM DESCRIPTION
1 Menu icon. When unlocked, displays set-up, control options and menu depending on the password level used.
Status view. When you log on, the iCOM CMS-controlled units and their status are listed on the main display. Clicking the
2
status icon toggles between the status and alarm summary.
Settings view. When selected, the settings options are listed on the main display. Options are:
•
•
3
•
Service view. When selected, the last and next preventive maintenance (PM) are listed next to the connected units.
See Maintenance scheduling and component run hours
4
You must be logged-on at the "Service" or "Advanced" level to access the service icon.
See Logging-on to iCOM CMS and Unlocking controls
Advanced view. When selected, advanced-level options are available on the menu.
5
You must be logged-on at the "Advanced" level to access the advanced icon.
See Logging-on to iCOM CMS and Unlocking controls
6 Search. Opens the "search" term-entry box. See
Lock/Unlock. Indicates that the options/menus at the level at which you are logged-on (user, service or advanced) are
7
accessible. See
1 Getting Started with iCOM CMS
Display Preferences, see Setting general display properties
Date/Time Setup, see Setting the date and time
iCOM-CMS settings are listed when you are logged-in at the "advanced" level, see:
• Setting the iCOM CMS Name
• Setting the Managing Mode
• Managing SSL Certificates
Logging-on to iCOM CMS and Unlocking controls
on page 9.
on page 10.
on page 31.
on page 32.
on page 32
on page 22.
on page 9.
on page 9.
Searching on page 10.
on page 9.
7
