2 USER OPERATION

2.1 Viewing setpoints for the cooling unit

NOTE: User-level access allows only viewing of setpoints. To adjust setpoints, you must have service-
or advanced-level access. See
To view the setpoints:
1. Click
The SETPOINTS panel opens.
2. Click the name of the unit for the setpoints you want to see.
The detail panel displays the setpoints for that unit.
Setpoints—user level
Temperature
Temperature that the unit maintains via cooling/reheat.
Fan Speed
Indicates the selected fan speed.
Run Modes
Indicates the operating mode of the unit.

2.2 Viewing the event log for a cooling unit

The event log is a list by date/time, unit, event type for all generated events and alarms and includes the
PIN ID for user-generated events and comments. Selecting an event log displays details about the event.
To view the event log:
1. Click
The EVENT LOG opens.
2. Click an event to display the detailed information.
Event-log fields
When
The date and time the event occurred.
2 User Operation
Editing setpoints for the cooling unit
> Setpoints.
> Event Log.
on page 19.
