SNMPv1/v2c Access
Enables/Disables SNMP access.
Authentication Trap
Enables/Disables SNMP authentication traps.
Device Name
Object name of the managed device.

3.5 Connection Settings

Configures the Ethernet connection between the unit and the iCOM CMS interface(s).
1. Click
The DISPLAY CONNECTIONS list opens.
2. In the Connection Type list, select the connection to configure.
3. In the display-connection PROPERTIES panel, click to toggle DHCP or Static mode.
• If you select DHCP, go to step 5.
• If you select Static, continue with the next step.
4. For static mode, enter the address, netmask, gateway and DNS-server settings.
5. Click Save.
Display-connection options
Mode
IP assignment type.
MAC Address
Media access control. (Read-only.)
IP Address
Network address of the iCOM CMS display/app.
Netmask
Divides IP addresses in subnet.
Gateway
IP address to the gateway to other subnets.
DNS Servers
IP addresses of the DNS servers for the organization.
3 Service and Advanced Operation
> Connection Settings.
