3.1.1 Setting-up Auto Run Mode
To properly navigate communication between the web UI and the wall-mounted thermostat controls, a
2-step procedure is required:
•
At the thermostat, set the temperature differential to 0º (zero).
•
On the web UI, set the heating and cooling setpoints, then the AI run mode.
Setting the Temperature Differential
The default minimum difference between heating and cooling setpoints is 5°F (2°C), and does not allow
the heating and cooling setpoints to be set inside this differential. To select setpoints for that do not
automatically adjust to the minimum difference, this differential must be zero.
NOTE: If you are having an issue with discrepancies in the setpoints and readings, and setting the
temperature differential does not help, please contact technical support at 1-800-543-2778.
1.
At the wall-mounted thermostat, open the flip door and press
the Function Settings section of the display.
2. Press
3. Press
Setting Heating, Cooling Setpoints and AI Run Mode
Before selecting AI (Auto) run mode, you must set the heating and cooling setpoints to the same value.
You must be in the run mode of the setpoint when setting it.
1.
Make sure the minimum difference between setpoints is 0°. See
Differential
2. Select heating run mode and set the heating setpoint on the web UI:
•
Click
•
In Run Mode, select Heating.
•
In Fan Speed, select the fan speed to use.
•
In Temperature, select the temperature setpoint.
•
Click Save.
3. Select cooling run mode and set the cooling setpoint on the web UI:
•
In Run Mode, select Cooling.
•
In Fan Speed, select the fan speed to use.
•
In Temperature, select the temperature setpoint.
•
Click Save.
4. In Run Mode, select AI, then click Save.
The status dial displays "AI" for about 2 minutes, and the wall-mounted thermostat is un-
responsive to button presses during this time while the configuration is communicating. After
that, the web UI displays the run mode currently in use, and the wall-mounted thermostat
indicates "AUTO" mode.
20
to set the differential to 0°, then press
to exit the function set-up.
on page 20.
> Setpoints, then select the unit to configure.
twice until
.
Setting the Temperature
Vertiv™ | Liebert® iCOM CMS™ Intaller/User Guide
