2. Select the Location to which the export will be saved.
NOTE: Only a single file may be saved in one location/on one USB drive. Saving to the same
location/drive overwrites the previous file.
3. Click Export in the lower-right corner, then OK in the confirmation dialog.
The export file is saved.
• Remove the USB drive from the port if used.
3.6.4 Importing iCOM CMS Settings
Import the settings from another unit to simplify configuring multiple units. The settings may be imported
from a file on the local disk or a USB drive.
1. Click
The IMPORT & EXPORT panel opens.
2. Click the Location from which the settings will be imported.
3. Click Import in the lower-right corner, then OK in the confirmation dialog.
The settings are imported.
• Remove the USB drive from the port if used.

3.6.5 Resetting hardware to factory defaults

There are two methods of performing a hardware factory reset, which returns the control board to the
factory-default settings for panel customization, display network settings, BMS settings, and custom
labels.
NOTE: The cloud registration status and connection settings are not reset when resetting to factory
defaults.
• Hardware-button reset
• Factory reset via the web UI.
Hardware factory reset using the button on the control board
1. Locate the 2 buttons on the CMS control board, see Figure 3.1 on the next page.
2. Press the right button (item 2), then immediately press-and-hold the left button (item 3) for at
least 5 seconds.
The LED on the control board (item 1) turns blue and flashes 5 times to indicate the 5-second
countdown.
The factory-default settings are restored and the display restarts.
3 Service and Advanced Operation
> Settings Management > Import and Export.
