3 SERVICE AND ADVANCED OPERATION

NOTE: With the exception of managing passwords, which is only available to the advanced-level user,
the service and advance menu options are the same.

3.1 Editing setpoints for the cooling unit

Setpoints are the means by which cooling-unit operation is controlled.
NOTE: Setpoint adjustment is only available via the web-based UI (and the wall-mounted controller).
You cannot modify setpoints using the mobile app.
NOTE: The default minimum difference between heating and cooling setpoints is 5°F (2°C), and does
not allow the heating and cooling setpoints to be set inside this differential. To select setpoints for that
do not automatically adjust to the minimum difference, this differential must be zero. We recommend
that you set the differential to zero at system start-up. See
page 20.
To edit the setpoints:
1. Click
The SETPOINTS panel opens.
2. Adjust the setpoint options, then click Save.
The setpoint is updated.
• Click Cancel to discard the changes.
Setpoint options
Temperature
Temperature that the unit maintains via cooling/reheat.
Fan Speed
Selects the fan speed.
NOTE: Auto fan-speed may only be set via the wall-mounted thermostat.
Run Modes
Selects the operating mode of the unit. Options are:
• Cooling
• Heating
• AI (Auto). See
• Fan
• Dehumidify—Not Supported. Do Not Use.
3 Service and Advanced Operation
> Setpoints.
Setting-up Auto Run Mode
Setting the Temperature Differential
on page 20.
on
