3.6 Backing-up and Restoring settings

iCOM CMS settings may be saved to a local disk or USB drive, and the saved files may exported or
imported to restore iCOM CMS if it is replaced or if a problem occurs. You can import and export
configuration settings to apply the configuration to other units, and you can also return iCOM CMS to
factory-default settings.

3.6.1 Backing-up iCOM CMS settings

Save a copy of the settings in a descriptively named file. Use a back-up file to restore the unit settings in
the event of a failure.
NOTE: Backing-up the iCOM CMS settings does not save settings stored on the cooling unit's iCOM
display, including setpoints, alarm settings, and sensor calibration. The back-up file also does not save
the cloud-registration status.
1. Click
The BACKUP & RESTORE panel opens.
2. Select the Location to which the backup will be saved.
NOTE: Only a single back-up file may be saved in one location/on one USB drive. Saving to the same
location/drive overwrites the previous file.
3. Click Backup in the lower-right corner, then OK in the confirmation dialog.
The back-up file is saved and a notification indicates that back up is successful.
• Remove the USB drive from the port if used.
3.6.2 Restoring iCOM CMS settings
Copy the settings from a back-up file to return iCOM CMS function to what it was before the problem or
failure. The settings may be restored from a file on the local disk or a USB drive.
1. Click
The BACKUP & RESTORE panel opens.
2. Click the Location from which the settings will be restored.
3. Click Restore in the lower-right corner, then OK in the confirmation dialog.
The settings are restored from the file, a notification indicates that restoration is successful,
and the display restarts.
• Remove the USB drive from the port if used.
3.6.3 Exporting iCOM CMS settings
Export a copy of the settings to a descriptively named file. Use exported settings to import the
configurations into other units.
NOTE: Exported settings do not include the settings stored on the cooling unit's iCOM display,
including setpoints, alarm settings, and sensor calibration.
1. Click
The IMPORT & EXPORT panel opens.
26
> Settings Management > Backup & Restore.
> Settings Management > Backup & Restore.
> Settings Management > Import and Export.
