Operation
The level of assistance is shown on the control computer. As a
bar diagram for the "ActiveLine" or "PerformanceLine" and as a
checkmark for the "Nyon" (see Figure B-20).
NOTICE: If the control computer is taken out of the holder, the last
riding mode shown is stored in the memory.

Lighting

When activating the lighting, "Light on" will appear for approx.
1 second in the text display field and "Light off" when deactivating
the lighting. The lighting symbol
is activated.
• To switch the lighting on or off, push the
Activating and deactivating the lighting does not affect the back-
light of the display. The backlight of the display is active as soon
as the e-bike or the control computer has been activated.

Charging external devices via USB

You can operate or charge external devices by connecting them
to the USB port on the control unit.
NOTICE: The control computer and a sufficiently charged
rechargeable battery must be inserted in the e-bike in order to
use and charge external devices.
will be shown when the light
button.
NOTICE
Risk of damage!
Irreparable damages may occur if the USB port is used
incorrectly.
• Read the user manual of the external device and check
whether the device is suitable for connection.
• Only use a compliant USB cable.
• The USB port must always be sealed with the protective
cap.
• Do not charge or operate external devices while driving
or in the rain.
1. Open the cover.
2. Use a USB 2.0 cable (Micro A or Micro B type) that complies
with applicable standards to connect the USB port of the
external device with the USB jack on the control computer.
38
