Start-up
1. To switch off the e-bike, push the
battery or the button on the control computer (see chapter
"Operation > E-bike > Deactivating the e-bike").
2. Hold the rechargeable battery tightly.
3. Insert the key in the lock and open the lock.
4. On-frame rechargeable battery (type 1):
• Carefully tilt the rechargeable battery out of the top holder.
In the process, do not tilt the rechargeable battery by more
than 7° relative to the frame (see Fig.: B-1).
• Pull the rechargeable battery up and out of the bottom holder.
7°
Fig.: B-1 Removing the on-frame rechargeable battery (type 1).
button on the rechargeable
Key Key
Upper
Holder
Bottom
Holder
4. Rack rechargeable battery (type 2):
• Carefully pull the rechargeable battery back and out of the
rechargeable battery holder (see Fig.: B-2).
5. To prevent damage, pull the key out of the lock.
6. To prevent damage, pull the key out of the lock.
Key
Fig.: B-2 Removing the luggage rack rechargeable battery (type 2).
Holder
