After enabling any of them, two objects are included by default:
"[AOx] Output Value (Control)": this object is supposed to receive
percentage values from the KNX bus, making the device generate a voltage
output between 0 V and 10 V (proportional to the percentage value).
"[AOx] Output Value (Status)": status object that shows, in terms of
percentage, the current value of the analogue output signal. This object is
automatically sent to the bus after receiving a new voltage setpoint, and when
the output status changes due to a lock order.
The following parameters can be configured from the corresponding tab:
Enable Lock by Object: when this checkbox is marked, the one-bit object
"[AOx] Lock" turns visible, as well as one more parameter:
➢ Lock Action: sets the particular state ("No Change" / "On" / "Off") the
output will adopt upon the reception of the value "1" through the "[AOx]
Lock" object. If set to "On", the desired Output Value needs to be
configured, in terms of percentage.
Note: while an output is locked, further voltage setpoints are ignored (the
device will respond with the current status of the output).
http://www.zennio.com
Figure 7 0-10V Analog Output X – Configuration (in detail).
