2.2 INPUTS

MAXinBOX FC 0-10V FAN incorporates two analogue/digital inputs, each
configurable as a:
Binary Input, for the connection of a pushbutton or a switch/sensor.
Temperature Probe, to connect a temperature sensor from Zennio.
Motion Detector, to connect a motion detector (models ZN1IO-DETEC-P
and ZN1IO-DETEC-X from Zennio).
Important: Older models of the Zennio motion detector (e.g., ZN1IO-DETEC
and ZN1IO-DETEC-N) will not work properly with this device.

2.2.1 BINARY INPUT

Please refer to the "Binary Inputs" user manual, available under the MAXinBOX FC 0-
10V FAN product section at www.zennio.com.

2.2.2 TEMPERATURE PROBE

Please refer to the "Temperature Probe" user manual, available under the MAXinBOX
FC 0-10V FAN product section at www.zennio.com.
Note: This device does not include support for custom NTC probes.

2.2.3 MOTION DETECTOR

It is possible to connect motion detectors (models ZN1IO-DETEC-P and ZN1IO-
DETEC-X from Zennio) to the input ports of MAXinBOX FC 0-10V FAN. This brings the
device with the possibility of monitoring motion and presence in the room, as well as
the light level. Depending on the detection, different response actions can be
parameterised.
Please refer to the "Motion Detector" user manual, available under the MAXinBOX FC
0-10V FAN product section at www.zennio.com, for detailed information about the
functionality and the configuration of the related parameters.
