Product description
Example
BASCJ_EN
V03 | 07.2015
Option
Water filter for internal drinking water tank
Mains water supply
For detailed information, please contact your sales partner.

Technical data

Nominal power*
Operating temperature
Minimum operating temperature (T min.)
Maximum operating temperature (T max.)
Overpressure
Working overpressure
Permissible working overpressure (p max)
Test overpressure
Water tank capacity
Bean hopper capacity
Increased bean hopper capacity (optional)
Grounds container capacity
External dimensions
Width
Height
Depth
Empty weight
Permanent noise level**
We reserve the right to make technical changes.
* For special equipment, see serial plate. The values specified here apply to the basic equip-
ment.
** The A-weighted noise level (slow) and Lpa (impulse) at the workplace of the operating per-
sonnel is below 70 dB (A) for every operating mode.
Description
The water filter can be installed in the internal
drinking water tank.
Capacity: 200 l
The tank is filled via a water inlet outside of
the machine. This option can be retrofitted.
1700 – 2300 W
Steam boiler Hot water boiler
130°C 86°C
130°C 102°C
Steam boiler Hot water boiler
2.5 bar 16 bar
16 bar 16 bar
24 bar 24 bar
2.2 l
250 g
400 g
20 coffee grounds cakes
305 mm
405 mm
445 mm
16 kg
<70 dB (A)
