2. Pin Configurations

ATF16V8B/BQ/BQL
2
Figure 1-1. Block Diagram
Table 2-1. Pin Configurations (All Pinouts Top View)
Pin Name
CLK
I
I/O
OE
VCC
Figure 2-1. TSSOP
I/CLK 1
I1 2
I2 3
I3 4
I4 5
I5 6
I6 7
I7 8
I8 9
GND 10
Figure 2-3. PLCC
I3 4
I4 5
I5 6
I6 7
I7 8
Function
Clock
Logic Inputs
Bi-directional Buffers
Output Enable
+5V Supply
Figure 2-2.
20 VCC
19 I/O
18 I/O
17 I/O
16 I/O
15 I/O
14 I/O
13 I/O
12 I/O
11 I9/OE
18 I/O
17 I/O
16 I/O
15 I/O
14 I/O
DIP/SOIC
I/CLK 1 20 VCC
I1 2 19 I/O
I2 3 18 I/O
I3 4 17 I/O
I4 5 16 I/O
I5 6 15 I/O
I6 7 14 I/O
I7 8 13 I/O
I8 9 12 I/O
GND 10 11 I9/OE
0364J–PLD–7/05
