Atmel ATF16V8B Manual page 22

15.2 20P3 – PDIP
A
SEATING PLANE
L
e
Notes: 1. This package conforms to JEDEC reference MS-001, Variation AD.
2. Dimensions D and E1 do not include mold Flash or Protrusion.
Mold Flash or Protrusion shall not exceed 0.25 mm (0.010").
2325 Orchard Parkway
San Jose, CA 95131
R
ATF16V8B/BQ/BQL
22
D
B1
E
C
eB
TITLE
20P3, 20-lead (0.300"/7.62 mm Wide) Plastic Dual
Inline Package (PDIP)
PIN
1
E1
A1
B
SYMBOL
eC
A
A1
D
E
E1
B
B1
L
C
eB
eC
e
COMMON DIMENSIONS
(Unit of Measure = mm)
MIN MAX
NOM
– – 5.334
0.381 – –
24.892 – 26.924 Note 2
7.620 – 8.255
6.096 – 7.112 Note 2
0.356 – 0.559
1.270 – 1.551
2.921 – 3.810
0.203 – 0.356
– – 10.922
0.000 – 1.524
2.540 TYP
DRAWING NO.
20P3
0364J–PLD–7/05
NOTE
1/23/04
REV.
D
