Summary of Contents for Atmel AVR XMEGA 8/16-bit High Performance Low Power Flash Microcontrollers
- Page 1 MiCROCOnTROLLERS ® AVR XMEGA trollers 8/16-bit High Performance Low Power Flash Microcon...
- Page 2 • Crypto engine, Timers/Counters and fast communication interfaces • Accurate and flexible Clock System with automatic clock failure protection ’s, and since day one the AVR philosophy has always been clear: Atmel is offering a wide range of AVR microcontrollers: 8-bit •...
- Page 3 Technology Reducing power consumption—maintaining performance picoPower — Best MCU power budget Atmel’s picoPower technology reduces power consumption in both sleep and active mode. With picoPower technology the embedded designer can reduce the applications power consumption while maintaining performance.
- Page 4 - Up to 32 MIPS - Single cycle execution - Instruction set optimized for C - 32x8 general purpose registers - hardware multiplier -> Perfect for 8/16-bit applications - Supports both AES and DES - Reducing CPU time and power consumption - Minimal CPU overhead for secure communication - Off-loads the CPU - Saves power...
-
Page 5: A Nalog C Omparator
XMEGA includes a programmable and power, CPU independent W XMEGA has flexible I/O pin confi g uration, sensing, and wake-up signaling plus p rogrammable - USART + SPI + Two-Wire Interface (I2C compatible) - External Bus Interface - Debugging/Programming BOD and a low sampled atch imer... -
Page 6: System Performance
AVR XMEGA™ MiCROCOnTOLLERS System Performance For Embedded systems, system performance is much more than a good MiPS number. it is important to have powerful peripherals and features that allow the application to run smoothly with minimum power consumption. AVR CPU and instruction Set The AVR XMEGA uses the AVR RiSC CPU which is created for high level C code development. -
Page 7: Dma Controller
DMA Controller The AVR XMEGA’s 4-channel Direct Memory Access (DMA) Controller enables fast, CPU independent data transfer between any locations in the data memory space and the peripherals. Flexible channel priority selection, several address- ing modes and double buffering capabilities. The DMA Controller a powerful module for all data oriented applications such as signal processing and industrial control. -
Page 8: Clock System
AVR XMEGA™ MiCROCOnTOLLERS Clock System AVR XMEGA’s clock system allow flexible change of frequency. Dynamic Clock Switching allows the Embedded Designer to tune performance and power consumption to fit the application. The internal PLL and prescaler can be used to scale the clock sources dynamically up or down to further match application requirements. With a built-in External Oscillator failure detection and internal RC oscillator with ±... - Page 9 AVR XMEGA comes with various interfaces that combined with DMA or Event System creates a powerful and fast communication platform. USART Full asynchronous and clocked synchronous operation. • Fractional BAUD Rate Generator • Master SPi mode • iRCOM module for irDA Compliance •...
-
Page 10: Ease Of Use
With both devices and tools available designers need good documentation. From the smallest devices to the largest processors, reference datasheets describing features and use are available from the Atmel web pages. Free application notes and library with complete code make it easy to start development. Partner software brings your product to the market with no hassle. - Page 11 Pb-free packaging alternative, complies to the European Directive for Restriction of Hazardous Substances (RoHS directive). Also Halide free and fully Green. d) include Battery backup function For samples and pricing offer, please contact you local distributor or Atmel sales representative. Pins/packages AVR XMEGA is delivered in different package options, including fully green versions.
- Page 12 Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN ATMEL’S TERMS AND CONDITIONS OF SALES LOCATED ON ATMEL’S WEB SITE, ATMEL ASSUMES NO LIABILITY WHAT-...
