13. ATF16V8B Ordering Information
13.1 ATF16V8B Standard Package Options
t t
PD S
(ns) (ns)
10 7.5
15 12
Note: The last time buy date is Sept. 30, 2005 for shaded parts.
13.2 ATF16V8B Green Package Options (Pb/Halide-free/RoHS Compliant)
t t
PD S
(ns) (ns)
10 7.5
15 12
13.3 Using "C" Product for Industrial
20J 20-lead, Plastic J-leaded Chip Carrier (PLCC)
20P3 20-lead, 0.300" Wide, Plastic Dual Inline Package (PDIP)
20S 20-lead, 0.300" Wide, Plastic Gull-wing Small Outline (SOIC)
20X 20-lead, 4.4 mm Wide, Plastic Thin Shrink Small Outline (TSSOP)
0364J–PLD–7/05
t
CO
(ns) Ordering Code
ATF16V8B-10JC
ATF16V8B-10PC
ATF16V8B-10SC
ATF16V8B-10XC
7
ATF16V8B-10JI
ATF16V8B-10PI
ATF16V8B-10SI
ATF16V8B-10XI
ATF16V8B-15JC
ATF16V8B-15PC
ATF16V8B-15SC
ATF16V8B-15XC
10
ATF16V8B-15JI
ATF16V8B-15PI
ATF16V8B-15SI
ATF16V8B-15XI
t
CO
(ns) Ordering Code
7 ATF16V8B-10JU
ATF16V8B-15JU
ATF16V8B-15PU
10
ATF16V8B-15SU
ATF16V8B-15XU
To use commercial product for Industrial temperature ranges, down-grade one speed grade
from the "I" to the "C" device (7 ns "C" = 10 ns "I") and de-rate power by 30%.
Package
20J
20P3
20S
20X
20J
20P3
20S
20X
20J
20P3
20S
20X
20J
20P3
20S
20X
Package
20J
20J
20P3
20S
20X
Package Type
ATF16V8B/BQ/BQL
Operation Range
Commercial
(0°C to 70°C)
Industrial
(-40°C to 85°C)
Commercial
(0°C to 70°C)
Industrial
(-40°C to 85°C)
Operation Range
Industrial
(-40°C to 85°C)
