Wireless Access Point
User Guide
Wait for the automatic reboot of the AP.
2.
Configure the switch.
Create IEEE 802.1Q VLANs described in the following table on the switch.
Port Connected
To
AP
Internal server
Router
Retain the default settings of other ports. For details, refer to the user guide of the
switch.
3.
Configure the router and the internal server.
To ensure your wireless devices connected to the AP can access the internet, you should
configure QVLAN function on your router and internal server which support QVLAN
function. Detailed VLAN parameters are listed as follows:
VLAN parameters configured on your router:
Port Connected
To
Switch
VLAN parameters configured on your internal server:
Port Connected
To
Switch
For configuration details, refer to the user guides of your router and internal server.
---End
Verification
Wireless devices connected to the SSID internet can access only the internet. Wireless
devices connected to the SSID oa can access only the intranet. Wireless devices connected
to the SSID VIP can access both the internet and the intranet.
Accessible VLAN ID
1, 2, 3, 4
3, 4
2, 4
Accessible VLAN ID
2, 4
Accessible VLAN ID
3, 4
Port Type PVID
Trunk 1
Trunk 1
Trunk 1
Port Type PVID
Trunk 1
Port Type PVID
Trunk 1
