Parameter description
Parameter
Radio (On/Off)
Radio
Status
Network Mode
Channel
SSID
SSID Status
MAC Address
Working Status
Security Mode
Description
It specifies whether the WiFi network at the corresponding
band is enabled.
On: It represents the WiFi network at the
−
corresponding band is enabled.
Off: It represents the WiFi network at the
−
corresponding band is disabled.
You can change the radio status on the Wireless Settings >
Radio Settings page.
It specifies the current network mode of the AP over the
2.4/5 GHz band. You can change the network mode on the
Wireless Settings > Radio Settings page.
It specifies the current working channel of the AP over the
2.4/5 GHz band. You can change the working channel on the
Wireless Settings > Radio Settings page.
It specifies the names of WiFi networks of the AP over the
2.4/5 GHz band. The AP supports eight WiFi networks over
2.4 GHz band and four over 5 GHz band. The first SSID in the
SSID status table is the primary SSID of each band. By
default, the WiFi network corresponding to the primary SSID
is enabled, and the other WiFi networks are disabled.
It specifies the physical address of the corresponding SSID.
It specifies whether the corresponding WiFi network is
enabled.
It specifies the security mode of the corresponding WiFi
network.
