Wireless Access Point
User Guide
Note
-
If you choose to power on your AP using DC power supply, connect the PWR port of
your AP to a DC power resource using the included power adapter.
-
If you have several IP-COM APs, to avoid IP address conflict, you should connect one
AP to a PoE port of your PoE switch first and set a new IP address for the AP. Then
repeat this procedure to connect other APs one by one and configure new IP
addresses for them respectively.
After finishing connection, ensure that the AP's LED indicator blinks and the lower-right
network icon on your computer is not displayed
2.
Configure the IP address of your computer (Example: Win7).
(1)
Right-click the network icon on the lower-right corner of your computer. Then click
Open Network and Sharing Center, Local Area Connection, and Properties.
(2)
Double-click Internet Protocol Version 4 (TCP/IPv4), select Use the following IP
address, set IP address to 192.168.0.x (x: 2 to 253. The IP address in this example is
192.168.0.10) and Subnet mask to 255.255.255.0.
(3)
Click OK.
3.
Log in to the web UI of your AP.
(1)
Start a web browser on your computer. Enter 192.168.0.254 in the address bar, and
press Enter.
(2)
Enter the user name and password (default: admin/admin) of the AP.
(3)
Click Login.
.
5
