- Page 1 Objet Desktop 3‐D Printer Site Preparation Guide Objet24 (V2): OBJ-14000 Objet30 (V2): OBJ-24000 DOC‐04002 Rev. D2 Stratasys Confidential and Proprietary Information...
- Page 2 This documentation contains proprietary information of Stratasys Ltd. This information is supplied solely to assist authorized users of this Stratasys 3D printing system. No part of this document may be used for other purposes, and it may not be disclosed to other parties.
-
Page 3: Table Of Contents
Objet Desktop 3-D Printer Site Preparation Guide Contents Introduction About this Guide ..................5 Installation and Training................. 5 Physical Description Configuration.................... 6 Size and Weight ..................6 Start‐Up Kit ....................6 Noise Level....................7 Shipment and Delivery Shipping Information and Responsibility ..........8 Shipping Pallets ..................8 Equipment ....................8 Unloading Space..................9 Unloading Assistance ................ - Page 4 Objet Desktop 3-D Printer Site Preparation Guide 5.11 Storage of Printing Materials..............18 5.12 Fire Control ..................... 19 Site Preparation Checklist ..............20 DOC-04002 Rev. D2...
-
Page 5: Introduction
The following topics are covered in this guide: • Physical Description • Shipment and Delivery • Site Requirements • Facility Requirements • Site Preparation Checklist Important: Since site preparation activities must be completed before the installation date, it is important for the customer to read this guide thoroughly and to complete the Customer Site Preparation Checklist at the end of this guide. On completion, the checklist should be faxed to customer’s Stratasys contac t person. For special operating conditions or if you have any questions about the site preparation procedure, contact your local Stratasys represen tative. 1.2 Installation and Training Installation and training take two work days: • Basic installation and adjustment— These procedures are described in the printer Installation Guides— Objet24/30 printers: DOC‐14040 Alaris30 printers: DOC‐04006 • Operator training including practice under supervision— Covers the operation and maintenance of the Objet Desktop. DOC-04002 Rev. D2... -
Page 6: Physical Description
Objet Desktop 3-D Printer Site Preparation Guide 2 Physical Description 2.1 Configuration The Objet 3‐D printing system consists of the following main components: • The printer • The printer computer (built into the printer) • A printer‐server workstation (computer provided by the customer) Figure 2–1 Objet 3-D printer 2.2 Size and Weight The following table shows the size and weight information for the printer. W × H × D (cm) W × H × D (inch) Weight (kg/lb) 82.6 ×... -
Page 7: Noise Level
Objet Desktop 3-D Printer Site Preparation Guide It is recommended that the start‐up kit be stored near the printer. The start‐up kit includes the following: • Customer Tool kit—Allen keys, screwdrivers, a mirror, a scraper, a spatula and a loupe for regular operation and maintenance. The tools are kept in a special pouch. • Consumable items—wiping cloths, pink paper, transparencies and so on, to maintain the printer for approximately two years. • Parts and accessories for emergency maintenance of the printing system. 2.4 Noise Level The noise level at a distance of 100 cm (39.4 in) from all sides of the printer is lower than 70 dB while printing. Impact noise was not found. DOC-04002 Rev. D2... -
Page 8: Shipment And Delivery
3 Shipment and Delivery 3.1 Shipping Information and Responsibility The Stratasys distributor will arrange shipment to th e customer’s facilities, as indicated in the “ship to” part of the invoice. It is the customer’s responsibility to provide the distributor with detailed delivery instructions. The customer is responsible for transporting the system to a suitably prepared installation site. Stratasys- ‐ certified Customer Support Engineers will advise the customer on site preparation, upon request. Caution: Equipment should be unpacked and installed by authorized Customer Support Engineers only. 3.2 Shipping Pallets The printer arrives on a wooden pallet. The pallet’s approximate size and ... -
Page 9: Unloading Space
Objet Desktop 3-D Printer Site Preparation Guide 3.4 Unloading Space In order to select the correct type of truck to deliver the printer, the presence or absence of a loading dock at the customer site must be identified. Check the route from the unloading location to the installation location and make sure there are no obstructions. 3.5 Unloading Assistance The customer must provide professional unloaders to unload the pallets and transfer them to the site. The unloaders will assist the distributor’s personnel in unpacking the equipment. 3.6 Training After the installation of the 3‐D printing system, an authorized Stratasys customer support engineer will train an operator and supervise the operation of the printer (1½ work days). The printer operator needs to be available during the entire installation and training period—two work days. DOC-04002 Rev. D2... -
Page 10: Site Requirements
Objet Desktop 3-D Printer Site Preparation Guide 4 Site Requirements The following factors should be considered when choosing a suitable location for the printer and server workstation: • Isolation from sources of vibration such as generators and central air‐conditioning systems. • Protection against sprinklers or pipes carrying liquids above the system. • Adequate free space at the front of the printer to ensure convenient access for loading materials and removing printed models. 4.1 Floor Area For convenience, Stratasys recommends that you place the printer on a stable table or stand with lockable wheels. You can order a printer stand from Stratasys using part number: OBJ‐04005. In normal operation, the printer requires a clear space of 20 cm behind it. Figure 4–1 is a sample floor plan, showing the space required for the system units and the minimum recommended service area for the printer. 60 cm 24" 24" 24" Printer... -
Page 11: Clear Space Above The Printer
Objet Desktop 3-D Printer Site Preparation Guide If your specific work area does not meet this minimum floor plan, consult with customer support to consider other possible arrangements. The system should not be located near heavy machinery (such as generators) that may cause electrical interference or high vibration levels. The system should be protected from sprinklers or pipes carrying liquids above the system. Similarly, do not place a Water Jet (used for cleaning models) within 5 meters (16 feet) of the printer. The server workstation must be located within 5 meters (16 feet) of the printer. The monitor, keyboard and mouse of the workstation are shared with the printer computer (the keyboard and the mouse must be USB‐type devices). Shelves and cabinets may be located in the vicinity of the printer to allow convenient storage of tools, parts, accessories, manuals and containers or model/support material. The temperature requirements for material storage are stated in Section 5.11.1, Storage and Transport Conditions on page 18. 4.2 Table Height & Strength The height of the table should be 62–72 cm (2 feet to 2 feet, 4 inches). This ... -
Page 12: Doors And Hallways
Objet Desktop 3-D Printer Site Preparation Guide 4.4 Doors and Hallways A minimum width of 65 cm (2 feet, 2 inches) is required for the printer to pass through—90 cm (3 feet) when the shipping pallet is included). If the printer must be turned (for example, to enter a doorway), the minimum hallway width required is 100 cm (3 feet, 4 inches). DOC-04002 Rev. D2... -
Page 13: Facility Requirements
3.5 A Table 3: Printer power rating A Type C circuit breaker with the following specification is recommended on the printer’s power line, subject to the local electrical code. Voltage Circuit Breaker 100–120 VAC 10 A 200–240 VAC Table 4: Circuit breaker requirements A stable and uninterrupted power supply is required. The power to the system should be supplied directly from the main electrical panel, without any tapped feeds on the line. 5.1.2 Grounding The printer is grounded through a single‐phase AC plug. Make sure that the ground connection in the wall outlet is properly grounded, in accordance with the local electrical safety codes. 5.1.3 Main Power Connectors The printer is shipped without a power cable. The power cable is supplied by your local Stratasys dealer. DOC-04002 Rev. D2... -
Page 14: Uninterruptible Power Supply (Ups)
Objet Desktop 3-D Printer Site Preparation Guide The following wall outlets are required: • One wall outlet behind the printer (for the printer) This should be connected directly to the main electrical panel. • Three wall outlets close to the printer (for the printer‐server workstation, the monitor, and an extra one for servicing requirements) 5.2 Uninterruptible Power Supply (UPS) To avoid printing problems due to power outages and other power problems, it is recommended that the customer install equipment that ensures a continuous power supply, with the following functionality and specifications. 5.2.1 Functionality The device used must have a USB alert output for “graceful system shutdown.” (Do not use a UPS device which only has a Serial Com signal output—RS‐232 Protocol.) 5.2.2 Specifications Refer to the relevant voltage below when selecting a UPS: Voltage Current Power 100–120 VAC, 50–60 Hz 16 Amps 1500 VA for 20 minutes 200–240 VAC, 50–60 Hz... -
Page 15: Server Workstation
Objet Desktop 3-D Printer Site Preparation Guide 5.4 Server Workstation The customer must provide a computer for the server workstation, with the following minimum requirements: ® Single Processor Pentium 4, 3.0 GHz; 512 KB cache Processor memory Professional (32 Bit only) ® • Microsoft Windows XP with Service Pack 2 ® Operating System •... -
Page 16: Client Workstations
Objet Desktop 3-D Printer Site Preparation Guide 5.5 Client Workstations The server workstation specifications (listed in Table 6) are relevant for all CAD and remote client workstations that send models to the printer, with the exception of the following: • Client workstations require a minimum of 2 GB RAM. • Client workstations do not require a USB connection on the mouse and keyboard. 5.6 Network A network connection is required near the server workstation. Point-to-Point To local network Crossed Network Cable 5 m (16' 5") Objet 3-D printing system Printer Server computer Workstation Figure 5–1 Network connection The printing system enables printing from all workstations connected to the customer’s network. -
Page 17: Air Conditioning
Objet Desktop 3-D Printer Site Preparation Guide 5.8 Air Conditioning Room air conditioning must be designed so that the temperature and humidity specifications described below are maintained when the system operates at full power. 5.8.1 Temperature The temperature in the room containing the printing system should be 18° C to 25° C (64.5° F to 77° F). 5.8.2 Humidity The relative humidity in the room containing the printer should be 30%–70% non‐condensing. The room requires constant refreshing of the humid air by appropriate ventilation units (refer to Section 5.8.3, Ventilation). 5.8.3 Ventilation Ventilation is required to maintain the necessary environment conditions in the room where the printing system is operated (see section 5.8.2). The ventilation system should have the capacity to replace all of the air in the room four times an hour. The printer evacuates air using an internal blower with a capacity of 106 CFM (cubic feet per minute) (180 m per hour). - Page 18 Objet Desktop 3-D Printer Site Preparation Guide Isopropanol is a common solvent that can generally be supplied by any chemical store. The full name of isopropanol is 2‐propanol or iso‐propyl alcohol (IPA). If isopropanol is not available, ethanol (ethyl alcohol) (>96%) is an alternative cleaning solvent. 5.11 Storage of Printing Materials 5.11.1 Storage and Transport Conditions Store containers of model and support materials, indoors, in a dry area with adequate ventilation and with the temperature kept between 16–27 degrees Celsius (60–81 degrees Fahrenheit). Similarly, transportation of these materials requires a dry environment kept between 16–27 degrees Celsius (60–81 degrees Fahrenheit). Printing materials are combustible. Never expose printing materials to flames, heat or sparks. Printing materials should be stored in conformance with applicable fire department and insurance company regulations and other applicable laws, regulations, codes and guidelines. 5.11.2 Shelf Life Printing materials can be used until the expiry date indicated on the container, provided that the container is undamaged. Inventory provisions should be made to insure that containers with the closest expiry date are used first. If the printing materials are not stored under the recommended conditions, their effective life is shortened.
- Page 19 Objet Desktop 3-D Printer Site Preparation Guide 5.12 Fire Control A gas fire extinguisher should be used in case of fire in or near the system. Other extinguishers are also acceptable, but the use of liquid fire extinguishers must be avoided. (Contact your local fire authorities for recommendations.) DOC-04002 Rev. D2...
- Page 20 Consult with an Stratasys-certified engineer if you have any questions related to the checklist and its implementation. Please be aware that Stratasys technical staff will not be able to arrive on site for installation and train- ing until this form is received and approved.
- Page 21 Objet Desktop 3-D Printer Site Preparation Guide Completed (according to spec.) Item and reference Notes Floor area and strength (section 4.1) Room layout (section 4.1) Access to final site, doors, hallways, etc. (section 4.4) Electrical power supply and outlets (sections 5.1.1—5.1.3) Circuit breaker (section 5.1.1) Grounding protection (section 5.1.2)
