- Page 1 Caution— To avoid exposure to skin irritants, wear protective gloves (provided) throughout this procedure. DOC-34032 Rev. A...
- Page 3 Support Print Head Replacement Instructions for Objet Desktop V3 Printers Removing the Support Print Head A. Put on protective gloves. Remove the print block cover. B. Remove screws B. C. Loosen screw C. A. Remove the Support print head card. While holding the print head, press down B.
- Page 4 Installing the Support Print Head Make sure that the Model head is installed as described in Model Print Head Replacement. Make sure the O-ring seals With the print head in the positioning jig, are installed on the print head. align it as shown. A.
- Page 5 Model Print Head Replacement Instructions for Objet Desktop V3 Printers Removing the Model Print Head To replace the Model print head, you must first remove the Support print head (see page 1). Remove the Model print head card. While holding the print head, press down B.
- Page 6 Installing the Model Print Head Make sure the O-ring seals With the print head in the positioning jig, are installed on the print head. align it as shown. A. Push jig upwards where marked “Push First.” Tighten the print head thumb screws. B.
